| . . | 24100J15069F1 | [1] | HYDR LINES, UPP | |
| 2. | ZC15X10500 | [4] | CLIP | KOB |
| 3. | 2444P798 | [1] | ELBOW | KOB |
| 4. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.40 ± 0.65 x OD 80mm |
| 5. | ZS23C12025 | [4] | CAPSCREW,Hex Socket Head, M12 x 52mm | KOBSCREW M12x1.75x25mm |
| 6. | ZW22K12000 | [4] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 7. | ZE13X12000 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 8. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 10. | ZW22X10000 | [14] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 12. | 2444Z2323D9 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2444R1172D3 |
| 13. | 2418P26575 | [1] | TUBE | KOB |
| 14. | 2418P26576 | [1] | TUBE | TUBE |
| 15. | 2416T26634 | [1] | BLOCK | KOB |
| 16. | ZS13C12060 | [4] | SCREW | KOBM12x1.75x60mm Superseded by part number: ZS18C12060 |
| 17. | ZW22X12000 | [10] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 18. | ZA23F28016 | [13] | CONNECTION | KOB1" PF - M36x1.50x49mm Long |
| 19. | ZD12P02900 | [18] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 21. | 2420T4331D4 | [3] | SCREW,M12 x 1.75 x 150mm | KOBM12x1.75x150mm |
| 22. | ZN13C12010 | [6] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 24. | ZS13C16055 | [4] | SCREW | KOBM16x2.0x55mm |
| 25. | ZW22X16000 | [6] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 26. | ZW13H16000 | [6] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 27. | ZA23F28012 | [2] | HYD CONNECTOR | KOB |
| 28. | ZD12P02400 | [4] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 30. | 2418P21335 | [1] | RIGID TUBE | KOB |
| 31. | 2432T2242 | [2] | CLAMP | KOBDouble -- 106x38x12mm (Ø23xØ29mm) |
| 32. | 2416P8799 | [1] | SUPPORT | KOB |
| 33. | ZS13C16035 | [2] | SCREW | KOBM16x2.0x35mm |
| 34. | ZW13H12000 | [2] | WASHER | KOB |
| 36. | 2418T23783 | [1] | TUBE | KOB Superseded by part number: 2418T20223 |
| 37. | 2418T23784 | [1] | TUBE | TUBE |
| 38. | 2418P21823 | [1] | RIGID TUBE | KOB |
| 39. | 2418T23785 | [1] | TUBE | KOB |
| 40. | 2418T23786 | [1] | TUBE | KOB |
| 41. | 2418T23787 | [1] | TUBE | KOB |
| 42. | 2418T23788 | [1] | TUBE | KOB |
| 43. | 2418T23789 | [1] | TUBE | KOB |
| 44. | 2444Z2399D7 | [4] | FLEXIBLE HOSE | KOBHOSE Superseded by part number: 2444R1173D1 |
| 45. | 2418P27522 | [1] | FLANGE | KOB |
| 46. | ZH22X08000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 47. | ZX21M08100 | [1] | FLEXIBLE HOSE | KOB1000mm Long (39-3/8 in) |
| 48. | ZH52X08000 | [1] | TEE,30 Degree Fl, Male, PF 1/2" x 1/2" x 1/2", O-Ring | KOB(Incls. O-Ring 237-6008) |
| 49. | ZX21M08143 | [1] | HOSE | KOB1430mm Long (56-19/64 in) Superseded by part number: ZX21M08145 |
| 50. | ZS13C12080 | [2] | SCREW | KOBM12x1.75x80mm Superseded by part number: ZS18C12080 |
| 51. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 52. | 2444Z2517D3 | [1] | HOSE | KOB |
| 53. | ZS13C12100 | [1] | SCREW | KOB Superseded by part number: ZS18C12100 |
| 54. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 55. | ZA33F22012 | [2] | ELBOW | KOB |
| 56. | ZX32M12120 | [1] | HOSE | KOB |
| 57. | 2418P21334 | [1] | RIGID TUBE | KOB |
| 58. | ZD11G06000 | [1] | O-RING,59.40mm ID x 65.60mm OD x 3.10mm | KOBID 59.40 ± 0.61 x OD 65mm |
| 59. | ZS13C10030 | [4] | SCREW | KOBM10x1.50x30mm Superseded by part number: ZS18C10030 |
| 60. | R44P0089D7 | [3] | COUPLING | KOB Superseded by part number: ZG15F04300 |
| 60-3. | R44P0089D7S3 | [2] | GASKET | KOB |
| 63. | ZS13C08030 | [2] | SCREW | KOBM08x1.25x30mm Superseded by part number: ZS18C08030 |
| 64. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 67. | 2418P22667 | [1] | TUBE | KOB |
| 68. | R44P0089D8 | [1] | ELASTIC JOINT,101mm ID x 148.8mm OD x 165.1mm L | KOBCOUPLING |
| 68-3. | R44P0089D8S3 | [2] | GASKET | KOB |
| 69. | 2436R393S4 | [1] | VALVE | KOBBYPASS |
| 70. | R44P0089D4 | [1] | COUPLING | KOB Superseded by part number: ZG15F05100 |
| 70-3. | R44P0089D4S3 | [2] | GASKET,50.85mm ID x 67.20mm OD | KOB |
| 72. | ZW11X08000 | [2] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 73. | 2444Z2341D4 | [1] | HOSE | KOB |
| 74. | 2416T26633 | [1] | BRACKET | |
| 75. | ZC36X28014 | [6] | CLAMP | KOBDouble Line -- 100x38x16mm (Ø30mm) |
| 76. | ZA33F18008 | [1] | ELBOW | KOB |
| 78. | 2444Z3359D6 | [1] | HOSE | KOB |
| 79. | 2432Z467 | [2] | CLAMP | KOB |
| 80. | 2405T1717 | [2] | BUSHING | KOB |
| 85. | ZA23F18008 | [3] | HYD CONNECTOR | KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied) |
| 87. | 2444Z3449D8 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2444R2486D1 |
| 88. | 2444Z2323D10 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2444R1172D4 |
| 89. | ZH22X12016 | [1] | HYD CONNECTOR | KOB |
| 90. | ZH22X12000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| 95. | 2418P23387 | [1] | RIGID TUBE | KOB |
| 96. | 2418P23388 | [1] | RIGID TUBE | KOB |
| 98. | ZA33F28016 | [1] | ELBOW | KOB |
| 100. | 2418P23553 | [1] | TUBE | KOB |
| 102. | 2416P16381 | [1] | BRACKET | |
| 103. | 2416P18274 | [1] | BRACKET | |
| 104. | 2420T4333D10 | [8] | SCREW | KOB |
| 106. | 2444R1125 | [1] | HOSE | KOB |
| 108. | 2436U2623F2 | [1] | VALVE | KOBHOLDING SEE (C.P.M.) |
| 109. | 2436U2817F1 | [1] | CONTROL VALVE | KOBSEE (C.P.M.) |
| 111. | 2416P17571 | [1] | BRACKET | |
| 112. | 2432T5299 | [2] | CLAMP | KOB |
| 113. | 2418T10357 | [2] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 114. | ZS13C10055 | [2] | SCREW | KOBM10x1.50x55mm Superseded by part number: ZS18C10055 |
| 115. | ZS18C12055 | [2] | SCREW,Hex, M12 x 55mm | KOBM12x1.75x55mm |
| 116. | ZW26X12000 | [3] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 117. | ZN13C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 118. | ZW16H10000 | [1] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 119. | ZE72X08000 | [1] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800) |
| 120. | 2418T24410D1 | [2] | SPACER | SPACER |
| 121. | 2418T24411D2 | [2] | SPACER | KOB |
| 122. | ZS13C12065 | [1] | SCREW | KOB Superseded by part number: ZS18C12065 |
| 123. | 2432R225D12 | [2] | CLAMP | KOBClamp, Single -- ID 31 x 69.5mm Long Superseded by part number: ZC46X31014 |
| 124. | ZS18C12030 | [1] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 125. | ZW16X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 126. | ZN18C12010 | [1] | NUT | KOBM12x1.75mm |
