凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2009 (9/09-12/11) (13-017[02]) - HARNESS, RH CONSOLE, VIPER-PRO Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
145 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87703505
|
[1] |
WIRE HARNESS
|
BN
RH Console, VIPER
|
| 2. |
BN310610
|
[1] |
ELEC CONNECTOR,Female, 10 Pin
|
BN
Cruise Set/Resume, J103
|
| 4. |
87695723
|
[1] |
ELEC CONNECTOR,Male , 3 Pole
|
RAC
Foam Volume, J113 Superseded by part number: 87055165
|
| 4A. |
87695625
|
[1] |
WIRE CONNECTOR,Locking, Green
|
BN
|
| 10. |
87695592
|
[1] |
CONTACT HOUSING,Female, 12 Pole
|
BN
Control Handle I/O, P101
|
| 10A. |
87695651
|
[1] |
LOCKING TAB,Wedge Lock
|
BN
|
| 11. |
87694112
|
[1] |
ELEC CONNECTOR,Female, 6 Pole
|
NH
Control Handle Power, P100 Superseded by part number: 225351C1
|
| 11A. |
87694150
|
[1] |
LOCKING TAB,Wedge Lock
|
NH
|
| 12. |
87692858
|
[1] |
ELEC CONNECTOR,Male
|
BN
De- Acel, J130
|
| 13. |
87707115
|
[1] |
CONTACT HOUSING,Female, 70 Pole
|
BN
Compartment Interface, P128
|
| 13A. |
87271606
|
[1] |
BOOT
|
BN
|
| 14. |
87271908
|
[1] |
ELEC CONNECTOR
|
BN
Transmission Shifter, P905
|
| 14A. |
87271909
|
[1] |
SEAL
|
BN
SEAL, 16W ORANGE
|
| 14B. |
87271910
|
[1] |
WEDGE
|
BN
TPA, RETAINER, 16F
|
| 14C. |
87271911
|
[9] |
PLUG
|
BN
CAVITY PLUG, BLUE
|
| 14D. |
87271912
|
[1] |
WEDGE
|
BN
CPA, MICRO PACK SERIES, R
|
| 14E. |
87271913
|
[1] |
WEDGE
|
BN
STRAIN RELIEF 16F 90DEGRE
|
| 16. |
87695724
|
[1] |
ELEC CONNECTOR,Male, 12 Pole
|
BN
2 Speed Axle, J127
|
| 16A. |
87698541
|
[1] |
LOCKING TAB,Wedge Lock, 12-Pin
|
ZED
|
