神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (05-006) - RADIATOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
453 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2452U426F1 | [1] | RADIATOR | KOB |
| 1. | 2452U426S1 | [1] | RADIATOR | KOBASSY |
| 2. | 2452U416S19 | [1] | OIL COOLER | KOB |
| 3. | 2452U221S111 | [1] | CAP | KOBPRESS Superseded by part number: 2414Z262 |
| 4. | 2452U416S4 | [1] | HOSE | KOBPIPE |
| 5. | 2452U221S113 | [2] | CLIP | KOBGRIP Superseded by part number: 2452U267S8 |
| 5. | 2452U416S6 | [1] | HOSE | KOBDRAIN |
| 7. | 2452U255S7 | [1] | COCK | KOB Superseded by part number: 2452U221S18 |
| 8. | 2452U221S1-2 | [6] | BOLT | KOBCAPSCREW |
| 9. | 2452U400S4 | [6] | BOLT | KOBCAPSCREW Superseded by part number: ZM22C10025 |
| 10. | 2452U416S10 | [2] | PACKING | KOB |
| 11. | 2452U416S11 | [1] | PACKING | KOB |
| 12. | 2452U416S12 | [1] | PACKING | KOB |
| 13. | 2452U221S4 | [3] | SCREW | KOB Superseded by part number: 2452U202S5 |
| 14. | 2452U416S14 | [1] | PROTECTOR | KOB |
| 15. | 2452U416S15 | [1] | SHROUD | KOB |
| 16. | 2452U416S16 | [1] | PROTECTOR | KOB |
| 17. | 2452U416S17 | [1] | PACKING | KOB |
| 18. | 2452U416S18 | [2] | PACKING | KOB |
