神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (05-008) - CONTROL ASSY. ENGINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
704 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J14520F1 | [1] | CONTROL UNIT | KOB |
| 1. | 2416P17815 | [1] | U-BRACKET | KOB |
| 2. | 2406T3100 | [1] | LEVER | KOB |
| 2-2. | 2405R61D17 | [1] | BUSHING | KOB Superseded by part number: 2405U104D006005 |
| 3. | 2406T3075 | [1] | LEVER | KOB |
| 3-2. | 2405R61D15 | [1] | BUSHING | KOB |
| 4. | 2406U197F3 | [1] | ACCELERATOR | KOB Superseded by part number: 2406U197F4 |
| . . | 2406U197F4R | [1] | REMAN-ELECTRIC MOTOR | KOBMD200C EXCAVATOR BTW YQU0701 - YQU2000, Reman for New P/N 2406U197F3 |
| . . | 2406U197F4C | [1] | CORE-ELECTRIC MOTOR | KOBReturn Number |
| 5. | 2420Z1326 | [1] | ROD | KOB |
| 6. | 2420Z1346 | [1] | ROD | KOBEND ASSY |
| 6-2. | 2405R61D17 | [2] | BUSHING | KOB Superseded by part number: 2405U104D006005 |
| 7. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 8. | ZS18C10035 | [4] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 9. | ZW26X10000 | [13] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | ZS18C10080 | [3] | SCREW,Hex, M10 x 80mm | KOBM10x1.50x80mm |
| 11. | ZN18C06005 | [1] | NUT | KOBM06x1.0mm |
| 12. | ZS23C06025 | [1] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 13. | ZW26X06000 | [3] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 14. | ZS18C06020 | [2] | SCREW,Hex, M6 x 20mm | KOBM06x1.0x20mm |
| 15. | 2419Z216 | [2] | PIN | KOB |
| 16. | 2419R9D1 | [3] | COTTER PIN | KOBOD 06mm x 21.2mm Long |
| 17. | 2420Z1347 | [1] | ROD | KOBEND ASSY |
| 17-2. | 2405R61D17 | [2] | BUSHING | KOB Superseded by part number: 2405U104D006005 |
| 18. | 2420T7359 | [1] | NUT | KOBM08x1.25mm -- Left Hand Threads |
| 19. | 2419T7017 | [1] | LEVER & PIN ASSY | KOBPIN ASSY |
| 20. | 2406R494D1 | [1] | FLEXIBLE CONTROL | KOBCABLE |
| 21. | 2416P17774 | [1] | BRACKET | KOB |
| 22. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 23. | 2432T4615 | [1] | LABEL | KOBDecal -- 45x45mm Red triangle |
| 24. | ZS18C10025 | [6] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 25. | 2416N6475 | [1] | BRACKET | KOB |
| 26. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
