神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (05-009[02]) - PANEL ASSY. INST Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
662 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J15123F2 | [1] | SPRING, LEAF | KOB |
| 1. | 2414J2493 | [1] | STAND | KOB |
| 1-10. | 2405R61D11 | [2] | BUSHING | KOB |
| 2. | 2427N3092 | [1] | PANEL | KOB |
| 3. | 2427P3553 | [1] | PLATE | KOBPANEL, INSTRUMENT |
| 4. | 2414P8209 | [1] | COVER | KOB |
| 5. | 2414N4691 | [1] | COVER | KOB |
| 6. | 2414T4945 | [1] | COVER | KOB |
| 7. | 2416T23659 | [1] | BRACKET | KOB |
| 9. | 2418T22758 | [1] | PLATE | KOB |
| 10. | 24100P2721F2 | [1] | LEVER | KOB |
| 10-1. | 2416P14378 | [1] | BRACKET | KOB |
| 10-3. | 2418T17877 | [1] | WASHER | KOB |
| 10-4. | R16T0137D2 | [6] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 1.6mm |
| 10-5. | R16T0040 | [1] | WASHER | KOB Superseded by part number: 2418T12345, 77266155 |
| 10-6. | ZN32C12011 | [1] | NUT | KOB |
| 10-14. | 2406P4789 | [1] | LEVER | KOB |
| 12. | 2489U276F2 | [1] | GAUGE, CLUSTER SEE FIGURE 05-010 | GAUGE, CLUSTER SEE FIGURE 05-010 |
| 15. | 2480U285F1 | [1] | POTENTIOMETER | KOB |
| 16. | 2421R180F1 | [1] | CIGARETTE LIGHTER | KOB Superseded by part number: YN81S00003P1 |
| 17. | 2480U371F1 | [1] | CONTROL | KOBCLUSTER, GAUGE |
| 18. | 2480U332F6 | [1] | CONTROL | KOB Superseded by part number: YN22E00358F1 |
| 20. | 2479U1281F5 | [1] | FUSE | KOBBOX |
| 20-3. | 2479U717S3 | [1] | PULLER | KOBFuse |
| 20-5. | 2479R655S10 | [4] | FUSE | KOB5 Amp Superseded by part number: 2479U717S5 |
| 20-8. | 2479U1281S8 | [1] | HARNESS | KOBHARNESS |
| 20-10. | 2479U1281S10 | [1] | BASE | KOB |
| 20-11. | 2479U1281S11 | [1] | COVER | KOB |
| 20-12. | 2479R655S9 | [10] | FUSE,20 Amp | KOB20 Amp |
| 20-13. | 2479U1281S13 | [1] | LABEL | KOB |
| 21. | 2447R135 | [1] | BUZZER | KOB |
| 22. | 2484R166D1 | [1] | RESISTOR,62 Ohm | KOB |
| 24. | 2479R1366 | [1] | RELAY | KOB |
| 25. | 2479R1424 | [5] | RELAY | KOBRELAY Superseded by part number: GG90Z00319F1 |
| 26. | 2479U1447 | [1] | RELAY,24V, 4 Sec Delay | KOBTIMER, BACK BUZZER |
| 28. | 2414T4530 | [4] | CAP | KOBSwitch -- 20x30mm |
| 29. | 2420Z1322 | [1] | GROMMET | KOB |
| 30. | 2420Z1325 | [1] | GROMMET | KOB |
| 31. | 2420Z1342 | [1] | GROMMET | KOB |
| 32. | 2406T3073 | [1] | GRIP | KOB |
| 33. | 2479U1190F13 | [1] | SWITCH | KOBHEAVY LIFT |
| 34. | 2479U1348F2 | [1] | SWITCH | KOBMODE SELECT |
| 35. | 2479U1278F2 | [1] | SWITCH | KOBWIPER |
| 38. | 2479U1190F7 | [1] | SWITCH | KOBAUTO ACCELE |
| 39. | 2479U1191F1 | [1] | SWITCH | KOBBUZZER STOP |
| 40. | 2479Z1447 | [1] | SWITCH | KOBMODE RELEASE |
| 41. | 2479U1190F6 | [1] | SWITCH | KOBSWING FLASHER |
| 42. | 2479U1190F1 | [1] | SWITCH | KOBWORKING LIGHT |
| 43. | 2479U1224F1 | [1] | SWITCH | KOBBACK BUZZER STOP |
| 44. | 2432T4345 | [1] | LABEL | KOB |
| 46. | 2420Z1323D1 | [4] | SCREW | KOBSEMS-BOLT |
| 47. | 2420R608D3 | [6] | SCREW,M6 x 16mm | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) Superseded by part number: ZM61C06016 |
| 49. | ZM11C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 51. | 2420R1090D2 | [4] | SCREW,M6 x 16mm | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) Superseded by part number: ZM46C06016 |
| 52. | 2420R608D2 | [21] | SCREW,M6 x 12mm | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) Superseded by part number: ZM61C06012 |
| 53. | 2420R1092D1 | [4] | BOLT,M5 x 35mm | KOBM05x0.8x35mm (Incls. Washer & Lockwasher) |
| 54. | 2420R1088D1 | [1] | BOLT,M4 x 6mm | KOBM04x0.7x06mm (Incls. Washer & Lockwasher) |
| 55. | 2420R579D1 | [2] | SCREW,M4 x 16mm | KOBM04x0.7x16mm (Incls. Washer & Lockwasher) |
| 57. | ZS18C10030 | [5] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 58. | ZW16X10000 | [5] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 59. | ZW26X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 60. | ZW26X06000 | [4] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 61. | ZW22X04000 | [2] | LOCK WASHER | KOBID 04 x OD 07.6 x Th 1.0mm Superseded by part number: ZW26X04000 |
| 62. | ZN18C06005 | [4] | NUT | KOBM06x1.0mm |
| 63. | 2420Z1352 | [1] | NUT | KOBM10x1.50mm |
| 64. | ZN11C04003 | [2] | NUT | KOBM04x0.7mm Superseded by part number: ZN18C04003 |
| 65. | 2479R1473F1 | [1] | HARNESS | KOBWIRING |
| 66. | 2479R1909 | [1] | HARNESS | KOB |
| 69. | 2405Z160D3 | [1] | BUSHING | KOB |
| 70. | 2405Z160D4 | [1] | BUSHING | KOB |
| 71. | 2479R2044F2 | [1] | SWITCH, STARTER | |
| 71-2. | 2479Z2735 | [1] | HARNESS | KOB |
| 71-3. | 2479U1483F1 | [1] | SWITCH, STARTER | |
| 71-3A. | 2479U346S2 | [1] | SWITCH | KOB |
| 71-3B. | 2420Z1030D2 | [1] | KIT | KOBPLATE Superseded by part number: PM50S01001P1 |
| 72. | 2432T5130 | [1] | LABEL | |
| 79. | 2479U1647D1 | [1] | WIRE HARNESS | KOB |
| 81. | 2432P2851 | [1] | LABEL, MITSUBISHI PARTS NO.--AS FOR THE ENGINE PARTS, REFER TO FOLLOWING "ENGINE PARTS" | |
| 8. | 2451U333S1 | [1] | RELAY | KOBSTARTER Superseded by part number: VAME049234 |
