神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (09-001) - GUARD ASSY. CAB Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
623 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J13721F2 | [1] | GUARD | KOB |
| l. | 2427P3666 | [1] | GUARD | KOB |
| 2. | 2427P3667 | [1] | GUARD | KOB |
| 3. | 2427P3668 | [1] | GUARD | KOB |
| 4. | 2427P3617 | [1] | GUARD CAB | GUARD CAB |
| 5. | 2427P3669 | [1] | GUARD | KOB |
| 5-5. | 2416Z487D4 | [1] | CUSHION | KOB |
| 6. | 2427P3670 | [1] | GUARD | KOB |
| 6-5. | 2416Z487D4 | [1] | CUSHION | KOB |
| 7. | 2427P3671 | [1] | GUARD | KOB |
| 7-5. | 2416Z487D4 | [1] | CUSHION | KOB |
| 8. | 2427P3672 | [1] | GUARD, CAB #8 10 | GUARD, CAB #8 10 |
| 10. | 2427P3623 | [1] | GUARD CAB | GUARD CAB |
| 11. | 2427P3624 | [1] | GUARD CAB | GUARD CAB |
| 12. | 2427P3674 | [1] | GUARD | KOB |
| 13. | 2427P3675 | [1] | GUARD | KOB |
| 13-4. | 2416Z487D4 | [1] | CUSHION | KOB |
| 14. | 2427P3676 | [1] | GUARD | KOB |
| 14-4. | 2416Z487D4 | [1] | CUSHION | KOB |
| 15. | 2432P2512 | [1] | LABEL | KOB |
| 16. | 2427P3868 | [1] | GUARD, CAB 10 | GUARD, CAB 10 |
