久保田零件查询T04800 NAME PLATE LABELSEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
697 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
6662147110
|
[2] |
LABEL KUBOTA
|
0.0088(lbs); 0.004
|
| 002. |
6620447120
|
[1] |
LABEL
|
0.0000(lbs); 0.000
|
| 003. |
6620447133
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 004. |
6670647140
|
[1] |
NAME PLATE 6
|
0.0000(lbs); 0.000
|
| 005. |
6670647150
|
[1] |
NAME PLATE 7
|
0.0000(lbs); 0.000
|
| 006. |
6620447180
|
[2] |
NAME PLATE
|
0.0044(lbs); 0.002
|
| 007. |
6659147190
|
[1] |
NAME PLATE 9
|
0.0022(lbs); 0.001
|
| 008. |
6620447190
|
[1] |
LABEL OIL
|
0.0022(lbs); 0.001
|
| 009. |
6620447210
|
[1] |
LABEL OIL
|
0.0000(lbs); 0.000
|
| 010. |
6620447220
|
[2] |
LABEL OIL
|
0.0022(lbs); 0.001
|
| 011. |
6620447230
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 012. |
6670647240
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 013. |
3122015970
|
[1] |
MARK
|
0.0022(lbs); 0.001
|
| 014. |
6670647250
|
[1] |
NAME PLATE
|
0.0022(lbs); 0.001
|
| 015. |
6670647260
|
[1] |
NAME PLATE
|
0.0022(lbs); 0.001
|
| 016. |
6660147230
|
[1] |
NAME PLATE
|
0.0440(lbs); 0.020
|
| 017. |
0401350040
|
[4] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 018. |
0451250040
|
[2] |
WASHER SPRING
|
0.0022(lbs); 0.001
|
| 019. |
0205450040
|
[2] |
NUT
|
0.0066(lbs); 0.003
|
| 020. |
6670647270
|
[1] |
LABEE
|
0.0022(lbs); 0.001
|
| 021. |
6670647280
|
[1] |
LABEE
|
0.0066(lbs); 0.003
|
| 022. |
6620447290
|
[1] |
LABEL
|
0.0220(lbs); 0.010
|
| 023. |
6620447410
|
[1] |
LABEL
|
0.0440(lbs); 0.020
|
| 023. |
6670447410
|
[1] |
LABEL
|
0.0418(lbs); 0.019
|
| 024. |
6670647330
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 025. |
6670647340
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 026. |
6620447350
|
[1] |
LABEL
|
0.0000(lbs); 0.000
|
| 027. |
6620447360
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 028. |
6620447370
|
[1] |
LABEL
|
0.0044(lbs); 0.002
|
| 029. |
6670647370
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 030. |
3517018290
|
[2] |
LABEL
|
0.0066(lbs); 0.003
|
| 031. |
3214018470
|
[1] |
MARK KUBOTA
|
0.0044(lbs); 0.002
|
| 032. |
6670647420
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 033. |
6670647460
|
[1] |
NAME PLATE
|
0.0044(lbs); 0.002
|
| 034. |
3511021990
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 035. |
6620447460
|
[1] |
NAME PLATE
|
0.0330(lbs); 0.015
|
| 036. |
5410224410
|
[4] |
RIVET
|
0.0022(lbs); 0.001
|
| 037. |
6620447510
|
[1] |
NAME PLATE
|
0.0990(lbs); 0.045
|
| 038. |
0300450610
|
[4] |
SCREW
|
0.0088(lbs); 0.004
|
| 039. |
6620447520
|
[1] |
LABEL
|
0.0022(lbs); 0.001
|
| 040. |
6620447530
|
[1] |
LABEL
|
0.0000(lbs); 0.000
|
| 041. |
6620447540
|
[1] |
LABEL
|
0.0000(lbs); 0.000
|
| 042. |
6620447550
|
[2] |
MARK
|
0.0066(lbs); 0.003
|
| 043. |
3526029790
|
[1] |
LABEL
|
0.0044(lbs); 0.002
|
| 044. |
3526029780
|
[1] |
LABEL ROPS
|
0.0000(lbs); 0.000
|
| 045. |
3526034910
|
[1] |
LABEL
|
0.0000(lbs); 0.000
|
| 046. |
3520025340
|
[1] |
LABEL PTO
|
0.0044(lbs); 0.002
|
