| 1. |
BN309564
|
[1] |
PUMP
|
BN
75CC Hydrostat, 90 Series, 810 Drive Pump
|
| 2. |
BN304157
|
[1] |
GEARBOX
|
BN
PTO Gear Box, RH, With 1-1/2" Dia 10 Tooth Splined Output Shaft, Mounted On The RH Side Of Transmission
|
| 2. |
BN304157R
|
[1] |
REMAN-PTO GEARBOX A.
|
BN
810 FLEX-AIR APPLICATOR, 4 WHEEL, PTO Gear Box, RH (2/12-)
|
| 2. |
BN304157C
|
[1] |
CORE-PTO GEARBOX A.
|
BN
Return Number
|
| 3. |
86986504
|
[1] |
PUMP
|
BN
60CC, Pressure Compensated
|
| 4. |
344035A1
|
[1] |
PLATE
|
BN
Rear, Hydrostatic Pump
|
| 5. |
344038A1
|
[1] |
MOUNTING PLATE
|
BN
Rear, Hydrostatic Pump
|
| 6. |
344374A1
|
[1] |
PLATE
|
BN
Front, Hydrostatic Pump
|
| 7. |
BN314397
|
[1] |
GUARD
|
BN
Lower, Pumps
|
| 8. |
87342890
|
[4] |
BOLT,7/16"-14 x 1-1/4", G5, DOR
|
BN
|
| 9. |
87310320
|
[4] |
NUT,7/16"-14, Grade B
|
BN
|
| 10. |
87529234
|
[12] |
WASHER,0.53" ID x 1.25" OD x 0.19" Thk
|
BN
|
| 11. |
87342964
|
[4] |
BOLT,Hex, 1/2"-20 x 1", G5, DOR
|
BN
|
| 12. |
87342932
|
[4] |
BOLT,Hex, 1/2"-13 x 2", G8, DOR
|
BN
|
| 13. |
87310321
|
[6] |
NUT,Prevailing Torque, 1/2"-13, GB, DOR
|
BN
Superseded by part number: 87343666
|
| 14. |
87342768
|
[4] |
BOLT,Hex, 3/8"-16 x 1-1/4", G5, Full Thd, DOR
|
BN
|
| 15. |
87343970
|
[4] |
NUT,3/8"-16, G8, DOR
|
A
|
| 16. |
87342928
|
[8] |
BOLT,1/2"-13 x 1-1/2", Gr 8
|
BN
|
| 17. |
84187116
|
[1] |
MOUNT
|
BN
Auxiliary Shaft Guard
|
| 18. |
84187113
|
[1] |
GUARD
|
BN
Auxiliary Shaft
|
| 19. |
84188742
|
[1] |
DRIVE SHAFT
|
BN
Hydrostatic Pump
|
| 20. |
86980420
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
BN
|
| 21. |
86980516
|
[2] |
NUT,Prev Torque, Hex, M12, 1.75 Pitch, Cl 8, DOR
|
CUR
|
