凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (35.220.03) - HYDROSTATIC PUMP, 75CC, 90 SERIES, 810 DRIVE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
311 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN309564
|
[1] |
PUMP
|
BN
75CC Hydrostat, 90 Series, 810 Drive, Includes Ref 2 - 16
|
| 2. |
BN65540
|
[2] |
VALVE
|
BN
Multi-Function 90 Series, Includes Ref 3 and 4
|
| 3. |
BN65541
|
[2] |
O-RING
|
BN
Multi-Function Valve Upper
|
| 4. |
BN65542
|
[2] |
O-RING
|
BN
Multi-Function Valve Lower
|
| 5. |
BN313402
|
[1] |
POPPET
|
BN
Charge Relief
|
| 6. |
BN313403
|
[2] |
SCREEN
|
BN
Control Filter
|
| 7. |
BN65546
|
[1] |
SEAL
|
BN
Lip, Shaft 75 CC Superseded by part number: 84132407
|
| 8. |
BN313405
|
[1] |
O-RING
|
BN
|
| 9. |
87271997
|
[1] |
FIP KIT
|
BN
Displacement Limiter
|
| 10. |
87267720
|
[4] |
BOLT
|
BN
M16 X 140, SHCS, 10.9
|
| 11. |
87272008
|
[1] |
SEAL
|
BN
Shaft, Includes Ref 7 and 8
|
| 12. |
BN306567
|
[1] |
CONTROL
|
BN
MDC Control, 12V, On/Off, Includes Ref 13 - 15
|
| 13. |
BN306569
|
[1] |
SOLENOID VALVE
|
BN
On/Off
|
| 14. |
BN306570
|
[1] |
GASKET
|
BN
Manifold
|
| 15. |
BN307684
|
[1] |
O-RING
|
CUR
Control Body Superseded by part number: 370460A1
|
| 16. |
BN313401
|
[1] |
O-RING
|
BN
|
| 17. |
70934882
|
[1] |
O-RING,0.103" Thk x 4.737" ID, -158, Cl 7, 75 Duro
|
LEC
.103 X 4.737 158 7, Used Between Hydrostatic Pump And Pressure Compensated Pump, Not Included With Pump Superseded by part number: 238-7158
|
