神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (16-004) - MANIFOLD ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
485 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R914F1 | [1] | INLET MANIFOLD | KOBCONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2436R914F2 |
| 1. | 2436R914S1 | [1] | BLOCK | KOBBLOCK |
| 2. | 2446R351F1 | [1] | FILTER | KOBASSY |
| 2-1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 2-2. | NSS | [1] | NOT SOLD SEPARAT | CONCAP |
| 2-3. | NSS | [1] | NOT SOLD SEPARAT | CONSCREEN |
| 2-4. | ZD11P02800 | [1] | O-RING | KOBID 27.70 ± 0.28 x OD 34mm |
| 2-5. | 2446R351S5 | [1] | O-RING | KOB |
| 3. | 2436R940F1 | [1] | VALVE | KOBASSY |
| 3-1. | 2436R940S1 | [1] | BACK-UP RING | KOB |
| 3-2. | 2436R940S2 | [1] | O-RING | KOB |
| 3-3. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET |
| 3-4. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 3-5. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 3-6. | 2436R940S6 | [1] | O-RING | KOB |
| 3-7. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER |
| 4. | 2436R943F1 | [1] | VALVE | KOBASSY Superseded by part number: 2436R943F2 |
| 4-1. | 2436R940S2 | [1] | O-RING | KOB |
| 4-2. | 2436R940S1 | [1] | BACK-UP RING | KOB |
| 4-3. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET |
| 4-4. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 4-5. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 4-6. | 2436R940S6 | [1] | O-RING | KOB |
| 4-7. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER ASSY |
| 5. | 2436R942F1 | [1] | VALVE | KOBASSY |
| 5-1. | 2436R940S1 | [1] | BACK-UP RING | KOB |
| 5-2. | 2436R940S2 | [1] | O-RING | KOB |
| 5-3. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET |
| 5-4. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 5-5. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 5-6. | 2436R940S6 | [1] | O-RING | KOB |
| 5-7. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER |
| 6. | 2436R941F1 | [1] | VALVE | KOBASSY |
| 6-1. | 2436R940S1 | [1] | BACK-UP RING | KOB |
| 6-2. | 2436R940S2 | [1] | O-RING | KOB |
| 6-3. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET |
| 6-4. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 6-5. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 6-6. | 2436R940S6 | [1] | O-RING | KOB |
| 6-7. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER |
| . . | 2436R940R100 | [1] | SEAL KIT | KOBREPAIR CONSISTS OF ITEM 3-1, 3-2, 3-6, 4-1, 4-2, 4-6, 5-1, 5-2, 5-6, 6-1, 6-2, 6-6 |
| . . | 2436R940R200 | [1] | SEAL KIT | KOBREPAIR CONSISTS OF ITEM 3-3 ~ 3-5, 3-7 |
| . . | 2436R941R200 | [1] | SEAL KIT | KOBREPAIR CONSISTS OF ITEM 6-3 ~ 6-5, 6-7 |
| . . | 2436R942R200 | [1] | SEAL KIT | KOBREPAIR CONSISTS OF ITEM 5-3 ~ 5-5, 5-7 |
| . . | 2436R943R200 | [1] | SEAL KIT | KOBREPAIR KIT CONSISTS OF ITEM 4-3 ~ 4-5, 4-7 |
