凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (35.359.01) - HYDRAULIC CONTROL VALVE BOX, SINGLE BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
248 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87267733
|
[1] |
HYDRAULIC VALVE
|
BN
With Fittings, Single Bin
|
| 1. |
87267733R
|
[1] |
REMAN-HYD VALVE
|
RAC
Reman With Fittings, Single Bin
|
| 1. |
87267733C
|
[1] |
CORE-VALVE HYD
|
RAC
Core Return Number
|
| 2. |
BN50144
|
[4] |
LOCK WASHER
|
BN
5/16" SS, Lock
|
| 3. |
86980378
|
[4] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
BN
|
| 4. |
BN50476
|
[8] |
BOLT,5/16"-18 x 0.75", Stainless
|
BN
|
| 5. |
344011A1
|
[1] |
HYDRAULIC VALVE
|
BN
7 Section Manifold
|
| 6. |
BN313449
|
[1] |
COVER
|
BN
Valve Box Side
|
| 7. |
BN55361
|
[4] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
