凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (35.359.07[01]) - VALVE WITH FITTINGS, DOUBLE BIN WITH AUGERS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
821 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87267731
|
[1] |
HYDRAULIC VALVE
|
BN
With Fittings, Double Bin With Augers, Complete, Includes Ref 2 - 12
|
| 2. |
87267741
|
[1] |
HYDRAULIC VALVE
|
BN
Without Fittings, Double Bin With Augers Superseded by part number: 87267731
|
| 3. |
BN302650
|
[6] |
FITTING
|
BN
13/16 -16 ORFS x 3/4 -16 ORB, Includes Ref 7 and 10
|
| 4. |
BN302655
|
[8] |
FITTING
|
BN
1-3/16"-12 ORFS x 1-1/16"-12 ORB, Includes Ref 8 and 11
|
| 5. |
BN57233
|
[1] |
FITTING
|
BN
1-3/16"-12 ORFS x 1-5/16"-12 ORB, Includes Ref 8 and 12
|
| 6. |
BN57223
|
[1] |
FITTING
|
BN
1-7/16"-12 ORFS x 1-5/16"-12 ORB, Includes Ref 9 and 12
|
| 7. |
9992298
|
[6] |
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
|
BHB
13/16", ORFS
|
| 8. |
9991976
|
[9] |
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
|
WIN
1-3/16", ORFS
|
| 9. |
9824050
|
[1] |
O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro
|
WIN
1-7/16", ORFS Superseded by part number: 87473574
|
| 10. |
128825
|
[6] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
NH
3/4", ORB
|
| 11. |
167266
|
[8] |
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
|
NH
1-1/16", ORB
|
| 12. |
167268
|
[2] |
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
|
WIN
1-5/16", ORB
|
