| . . | 2437U407F1 | [1] | HYDRAULIC PUMP | KOBASSY CONSISTS OF THE FOLLOWING PARTS |
| (79). | 2436R884F1 | [1] | VALVE | KOBASSY SEE FIGURE 14-003 Superseded by part number: 2436R884F3 |
| 111. | 2437U213S111 | [1] | SHAFT | KOB(F) |
| 113. | 2437U213S113 | [1] | SHAFT | KOB(R) |
| 114. | 2437U213S114 | [1] | COUPLING | KOB |
| 123. | 2437U213S123 | [2] | BEARING | KOBROLLER Superseded by part number: 2441U436S123 |
| 124. | 2437U213S124 | [2] | BEARING | KOBNEEDLE Superseded by part number: 6025Z12D1M |
| 127. | 2441U723S127 | [4] | SPACER | KOBBEARING |
| 141. | NSS | [2] | NOT SOLD SEPARAT | CONCYLINDER BLOCK |
| 151. | NSS | [18] | NOT SOLD SEPARAT | CONPISTON |
| 152. | NSS | [18] | NOT SOLD SEPARAT | CONSHOE |
| 153. | 2437U213S153 | [2] | PLATE | KOB Superseded by part number: LC10V00010S153 |
| 156. | 2437U213S156 | [2] | BUSHING | KOB Superseded by part number: YN10V00005S156 |
| 157. | 2437U213S157 | [18] | SPRING | KOB |
| 158. | 2437U213S158 | [2] | SPACER | KOB Superseded by part number: YN10V00005S156 |
| 211. | 2441U242S211 | [2] | PLATE | KOBSHOE |
| 212. | NSS | [2] | NOT SOLD SEPARAT | CONPLATE |
| 214. | NSS | [2] | NOT SOLD SEPARAT | CONBUSHING |
| 251. | 2437U213S251 | [2] | PLATE | KOB |
| 261. | 2437U213S261 | [1] | COVER | KOBSEAL |
| 263. | 2437U213S263 | [1] | COVER | KOBREAR |
| 271. | 2437U213S271 | [2] | CASE | KOB |
| 312. | 2437U213S312 | [1] | COUPLING BLOCK | KOBVALVE |
| 313. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, VALVE (R) |
| 314. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, VALVE (L) |
| 325. | 2437U407S325 | [1] | CASE | KOBCASE, VALVE |
| 401. | 2437U213S401 | [8] | SCREW | KOBCAP |
| 406. | ZS23C08025 | [8] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 407. | ZS23C06055 | [3] | CAPSCREW,Hex Socket Head, M6 x 55mm | KOBSCREW M06x1.0x55mm |
| 466. | 2441U667S466 | [3] | PLUG | KOB1/4" PF |
| 468. | 2441U436S469 | [3] | PLUG | KOB |
| 490. | 2441U722S490 | [24] | PLUG | KOB1/16" NPTF |
| 531. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
| 532. | 2437U213S532 | [2] | PISTON | KOB |
| 534. | 2437U213S534 | [2] | STOP | KOB |
| 535. | 2437U213S535 | [2] | STOP | KOB |
| 541. | NSS | [4] | NOT SOLD SEPARAT | CONSEAT |
| 543. | NSS | [2] | NOT SOLD SEPARAT | CONSTOPPER |
| 544. | NSS | [2] | NOT SOLD SEPARAT | CONSTOPPER |
| 545. | NSS | [4] | NOT SOLD SEPARAT | CONBALL |
| 548. | NSS | [2] | NOT SOLD SEPARAT | CONPIN, FEEDBACK |
| 702. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 710. | ZD12G09500 | [2] | O-RING,3.1mm Thk x 94.4mm ID, 90 Duro | KOBO-Ring -- ID 94.40 ± 0.81 x OD 100mm |
| 717. | ZD12G14500 | [4] | O-RING,144.40mm ID x 150.60mm OD x 3.10mm | KOBID 144.40 ± 1.16 x OD 150mm |
| 724. | ZD12P00800 | [16] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 725. | ZD12P01100 | [8] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 727. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 728. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 732. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 774. | 2441U436S774 | [1] | OIL SEAL | KOB Superseded by part number: 2441U267S774 |
| 789. | ZD85P01800 | [2] | RING | KOBBack-Up -- ID 18 x OD 22 x Th 1.25mm |
| 792. | ZD85G03500 | [2] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 806. | ZN11C16010 | [2] | NUT | KOBM16x2.0mm |
| 808. | ZN11C20012 | [2] | NUT | KOBM20x2.50mm |
| 824. | R13N0013E22 | [2] | SNAP RING | KOBSNAP Superseded by part number: ZR16X04000 |
| 885. | 2441U723S885 | [2] | PIN | KOB |
| 886. | ZP26D06014 | [4] | PIN | KOBRoll -- OD 06 x 14mm Long |
| 901. | ZS91C01000 | [2] | BOLT | KOBEye -- M10x1.50x18mm |
| 953. | 2437U188S953 | [2] | CAP,M10 x 20mm | KOBSETSCREW |
| 954. | 2437U213S954 | [2] | SCREW | KOBSET |
| 981. | 2437U407S981 | [1] | LABEL | KOBNAME PLATE |
| 983. | 2437U407S983 | [2] | RIVET | KOBSCREW |
| . . | 2437U172S11 | [1] | PISTON | KOBCONSISTS OF ITEM 151, 152 Superseded by part number: YN10V00003S011 |
| . . | 2437U213S13 | [1] | REPAIR KIT | KOBCYLINDER ASSY (R) CONSISTS OF ITEM 141, 313 |
| . . | 2437U213S14 | [1] | REPAIR KIT | KOBCYLINDER ASSY (L) CONSISTS OF ITEM 141, 314 |
| . . | 2437U213S30 | [1] | REPAIR KIT | KOBPLATE ASSY CONSISTS OF ITEM 212, 214 |
| . . | 2437U219S41 | [1] | REPAIR KIT | KOBVALVE ASSY, CHECK CONSISTS OF ITEM 541, 543, 545 |
| . . | 2437U219S42 | [1] | VALVE | KOBVALVE ASSY, CHECK CONSISTS OF ITEM 541, 544, 545 |
| . . | 2437U213S530 | [1] | REPAIR KIT | KOBPIN ASSY CONSISTS OF ITEM 531, 548 |
