凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (35.359.11) - VALVE BOX ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
642 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN307047
|
[4] |
PIN
|
BN
3/8, With Shoulder
|
| 2. |
84130864
|
[1] |
BOX
|
BN
Hydraulic Valve
|
| 3. |
BN306268
|
[1] |
COVER
|
BN
Access, Valve Box Superseded by part number: 84558910
|
| 4. |
BN310283
|
[2] |
PIN
|
BN
3/8, With 3/4 Shoulder
|
| 5. |
BN50138
|
[2] |
WASHER,1/4", SS
|
BN
|
| 6. |
BN50146
|
[16] |
WASHER,3/8", Stainless
|
BN
|
| 7. |
BN50212
|
[2] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 8. |
BN50258
|
[4] |
BOLT,3/8"-16 X 1.25", Stainless
|
BN
|
| 9. |
BN50254
|
[5] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 10. |
BN50759
|
[16] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 11. |
BN52033
|
[4] |
BOLT,1/4"-20 X 5/8", Stainless Steel
|
BN
|
| 12. |
BN55359
|
[6] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 13. |
BN65808
|
[2] |
LATCH
|
BN
Adjustable
|
| 14. |
BN67852
|
[1] |
COVER
|
BN
RH Side
|
| 15. |
BN67855
|
[1] |
COVER
|
TYR
LH Side
|
| 16. |
BN67857
|
[2] |
ANGLE
|
BN
Mount, Side Cover
|
| 17. |
BN71007
|
[6] |
CLIP,3/16" Hairpin
|
BN
Hairpin, 3/16" #8
|
| 18. |
87265990
|
[1] |
PLUG
|
BN
Button, Flush Type
|
