| . . | 24100J6339F7 | [1] | TANK ASSY.HYDR | |
| 2. | 2446R307F2 | [1] | STRAINER ELEMENT | KOBSUCTION |
| 2-1. | 2446R307S1 | [1] | STRAINER ASSY. | KOB Superseded by part number: YN50V00002S001 |
| 2-3. | 2446R110S2 | [1] | HOLDER | KOBHOLDER |
| 2-4. | ZN11C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 2-5. | 2446R110S6 | [1] | SPRING | KOB |
| 2-6. | 45Z91D6 | [1] | O-RING | KOBID 97.79 ± 0.38 OD 108.45mm |
| 2-7. | 2446R110S5 | [1] | SCREW | KOB |
| 3. | 2418T4572D1 | [2] | FLANGE | KOB |
| 5. | ZD11G16500 | [1] | O-RING,164.30mm ID x 175.70mm OD x 5.70mm | KOBID 164.30 ± 1.30 x OD 175.7mm |
| 6. | ZD11P13000 | [2] | O-RING | KOBID 129.6 ± 1.05 x OD 140mm |
| 7. | 2446R147 | [2] | ELEMENT | KOBRETURN Superseded by part number: 24046Z15P |
| 8. | 2446U119S3 | [2] | VALVE | KOB |
| 9. | 2446U119S2 | [2] | SPRING | KOB |
| 11. | 2446U214F1 | [1] | HYDRAULIC OIL FILTER | KOB |
| 11-1. | 2446U214S1 | [1] | BODY | KOBHEAD |
| 11-2. | 2446U214S2 | [1] | VALVE ASSY | VALVE ASSY |
| 11-3. | 2446U141S2 | [1] | SPARE PART | HIT Superseded by part number: S15510-20200 |
| 11-4. | 2446U214S4 | [1] | LABEL | |
| 11-5. | 2446U214S5 | [1] | NAME-PLATE | |
| 13. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 15. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 16. | ZA93N28000 | [1] | TUBE NUT | KOB |
| 17. | ZA93S28000 | [1] | FERRULE | KOB |
| 18. | 2416T13296 | [1] | U-BRACKET | KOB |
| 19. | 2489R293F1 | [1] | LEVEL GAUGE | KOB Superseded by part number: YN58S00009F1 |
| 19-1. | 2489R173S1 | [1] | GAUGE | KOB |
| 19-2. | 2489R174S3 | [2] | BOLT | KOBSpecial -- M10x1.50x40mm Long |
| 19-3. | 2489R174S2 | [2] | BLOCK | KOBGAUGE, LEVEL |
| 19-4. | ZD11P01800 | [4] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 19-5. | ZD11P01000 | [4] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 21. | ZS13C16040 | [4] | SCREW | KOBM16x2.0x40mm |
| 22. | ZS18C12025 | [12] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 24. | ZS23C06010 | [3] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 25. | ZS13C10020 | [4] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 26. | ZW22X16000 | [4] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 27. | ZW26X12000 | [12] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 28. | ZW22K06000 | [3] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 29. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 31. | ZW11X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 32. | ZE72X16000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| 36. | 2418T17563 | [1] | FLANGE | FLANGE |
| 37. | ZE72X12000 | [1] | PLUG | KOB(3/4" PF) (Incls. O-Ring ZD12P02400) |
| 38. | ZA33F28016 | [1] | ELBOW | KOB |
| 40. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 41. | 2489R302F1 | [1] | SWITCH | KOBLEVEL |
| 41-2. | 2489R302S2 | [1] | O-RING | KOB |
| 42. | 2444Z2872 | [1] | TEE | KOB |
| 43. | ZC45X06007 | [1] | CLIP | |
| 44. | ZS18C06016 | [1] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 45. | ZW26X06000 | [1] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 50. | 2427J1398 | [1] | TANK. HYDR | |
| 51. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| . . | 24046Z15 | [2] | ELEMENT | KOBCONSISTS OF REF. 6 & 7 Superseded by part number: 24046Z15P |
