| 1. |
BN309765
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 20" Long, Valve to LH Tip Fold Rod Side Tube
|
| 2. |
BN314468
|
[2] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 9/16-18 Female ORFS Swivel x 1/4" ID x 24.5" Long, Bulkhead Fitting to Boom Level Cylinder, Rod Side
|
| 3. |
BN314469
|
[2] |
HOSE,23.00"
|
BN
11/16-16 Female ORFS Swivel x 9/16-18 Female ORFS Swivel x 1/4" ID x 23" Long, Bulkhead Fitting to Boom Level Cylinder, Base Side
|
| 4. |
BN314945
|
[4] |
HOSE ASSY.
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel x 3/8" ID x 25" Long, Boom Level Tubes to Bulkhead Fittings
|
| 5. |
BN309837
|
[2] |
HOSE
|
BN
11/16-16 Female ORFS Swivel Elbow x 9/16-18 Female ORFS Swivel x 1/4" ID x 170" Long, Boom Tip Fold Tube to Outer Boom Cylinder, Rod End
|
| 6. |
BN309838
|
[2] |
HOSE
|
BN
11/16-16 Female ORFS Swivel Elbow x 9/16-18 Female ORFS Swivel x 1/4" ID x 151" Long, Boom Tip Fold Tube to Outer Boom Cylinder, Base End
|
| 7. |
BN309976
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 23.5" Long, Valve to RH Tip Fold Tube, Rod Side
|
| 8. |
BN309977
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 26" Long, Valve to RH Tip Fold Tube
|
| 9. |
BN309979
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 28.5" Long, Valve to LH Tip Fold Tube
|
| 10. |
BN309980
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 21" Long, Valve to RH Boom Level Tube, Rod Side
|
| 11. |
BN309981
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 25.5" Long, Valve to RH Boom Level Tube
|
| 12. |
BN309982
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 23" Long, Valve to LH Boom Level Tube, Rod Side
|
| 13. |
BN309983
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 33.5" Long, Valve to LH Boom Level Tube
|
| 14. |
86986294
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 100" Long, Valve to RH Boom Fold Cylinder, Rod Side
|
| 15. |
BN309985
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel Elbow x 9/16-16 Female ORFS Swivel Elbow x 1/4" ID x 95" Long, Valve to RH Boom Fold Cylinder
|
| 16. |
86986369
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel x 11/16-16 Female ORFS Swivel Elbow x 1/4" ID x 55" Long, Valve to LH Boom Fold Cylinder, Rod Side
|
| 17. |
BN309987
|
[1] |
HOSE
|
BN
11/16-16 Female ORFS Swivel Elbow x 9/16-16 Female ORFS Swivel Elbow x 1/4" ID x 55" Long, Valve to LH Boom Fold Cylinder
|
| 18. |
BN302549
|
[6] |
ELBOW
|
BN
9/16-18 ORFS x 9/16-18 ORB, Includes Ref 25 and 26
|
| 19. |
BN302641
|
[4] |
FITTING
|
BN
9/16-18 ORFS x 9/16-18 ORB, Includes Ref 25 and 26
|
| 20. |
9993141
|
[26] |
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
|
BAS
11/16", ORFS
|
| 21. |
BN302553
|
[2] |
ELBOW
|
BN
11/16-16 ORFS x 9/16-18 ORB, Includes Ref 20 and 26
|
| 22. |
BN313268
|
[2] |
ORIFICE
|
BN
.042, -6 Disk
|
| 23. |
87657658
|
[4] |
UNION
|
BN
11/16"-16 ORFS x 11/16"-16 ORFS, Includes Ref 20
|
| 24. |
87657660
|
[4] |
BHD LOCK NUT
|
BN
11/16"-16
|
| 25. |
9825770
|
[10] |
O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro
|
WIN
9/16", ORFS
|
| 26. |
9617873
|
[24] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
9/16", ORB
|
| 27. |
BN302646
|
[12] |
FITTING
|
BN
11/16-16 ORFS x 9/16-18 ORB, Includes Ref 20 and 26
|
