凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (35.747.01) - WET BOOM HYDRAULIC GROUP, 60'/70' BOOMS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
670 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN302558
|
[1] |
ELBOW
|
BN
13/16-16 ORFS x 3/4-16 ORB, Includes Ref 13 and 14
|
| 2. |
BN302560
|
[2] |
FITTING
|
BN
13/16-16 ORFS x 1-1/16-12 ORB, Includes Ref 13 and 15
|
| 4. |
BN302651
|
[2] |
FITTING
|
BN
13/16-16 ORFS x 7/8-14 ORB, Includes Ref 13 and 16
|
| 5. |
BN302652
|
[1] |
FITTING
|
BN
13/16" -16 OFRS x 1-1/16" -12 ORB, Includes Ref 13 and 15
|
| 6. |
87266236
|
[1] |
VALVE
|
BN
Product, PWM
|
| 7. |
BN311741
|
[1] |
HOSE
|
BN
13/16-16 ORFS Swivel x 13/16-16 ORFS Swivel Elbow x 1/2" ID x 62" Long, Product Control Valve to Filter Manifold
|
| 8. |
BN311742
|
[1] |
HOSE,16.00"
|
BN
13/16-16 ORFS Swivel x 13/16-16 ORFS Swivel x 1/2" ID x 16" Long, Product Pump to Product Control Valve
|
| 9. |
BN311743
|
[1] |
HOSE
|
BN
13/16-16 ORFS Swivel x 13/16-16 ORFS Swivel Elbow x 1/2" ID x 97" Long, Product Pump to Chassis Return Manifold
|
| 10. |
BN50142
|
[2] |
WASHER,5/16", Stainless Steel
|
BN
|
| 11. |
BN52324
|
[2] |
BOLT
|
BN
5/16"-18 X 2-3/4", Stainless Steel
|
| 12. |
BN55361
|
[2] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 13. |
9992298
|
[6] |
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
|
BHB
13/16", ORFS
|
| 14. |
128825
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
NH
3/4", ORB
|
| 15. |
167266
|
[3] |
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
|
NH
1-1/16", ORB
|
| 16. |
167269
|
[2] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
WIN
7/8", ORB
|
