凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (35.748.04) - CONVEYOR AND MAIN AUGER HYDRAULIC TUBES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
832 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN29783
|
[3] |
CLAMP
|
BN
Single, 1/2" Tube
|
| 2. |
BN306975
|
[1] |
TUBE
|
BN
Main Auger Gate
|
| 3. |
BN306976
|
[1] |
TUBE
|
BN
Main Auger Gate, Rod End
|
| 4. |
BN306981
|
[1] |
TUBE
|
TYR
Conveyor, RH
|
| 5. |
BN307082
|
[1] |
CLAMP
|
BN
Pair 1.25" Tube
|
| 6. |
BN307911
|
[6] |
CLAMP
|
BN
Dual, 3/8 Tube
|
| 7. |
BN307913
|
[1] |
CLAMP
|
BN
Dual, 1/2 Pipe
|
| 8. |
BN309483
|
[1] |
PLATE
|
BN
Clamp Top, Single Clamp
|
| 9. |
BN309484
|
[1] |
PLATE
|
BN
Top, Dual, Size 3
|
| 10. |
BN309485
|
[3] |
PLATE
|
BN
Top, Single, Size 2
|
| 11. |
BN309486
|
[3] |
PLATE
|
BN
Top, Dual, Size 1
|
| 12. |
BN309848
|
[2] |
SCREW,Hex, 5/16" - 18 x 3", SST
|
BN
|
| 13. |
BN309849
|
[2] |
CLAMP
|
BN
Dual, 1.25 Tube
|
| 14. |
BN309850
|
[2] |
PLATE
|
BN
Dual, Size 5
|
| 15. |
BN50241
|
[1] |
BOLT,5/16"-18 X 2-1/4", Stainless Steel
|
BN
|
| 16. |
BN55359
|
[11] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 17. |
BN55361
|
[3] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 18. |
BN55366
|
[6] |
BOLT,1/4"-20 x 2.00", Stainless Steel
|
BN
|
| 19. |
BN67050
|
[5] |
BOLT,1/4"-20 X 3.00", Stainless Steel
|
BN
|
| 20. |
BN311570
|
[2] |
CLAMP
|
BN
Dual, 1.50 Tube
|
| 21. |
BN309845
|
[1] |
SCREW,Hex, 5/16" - 18 x 5", SST
|
BN
|
| 22. |
9993141
|
[4] |
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
|
BAS
11/16", ORFS
|
| 23. |
9992298
|
[2] |
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
|
BHB
13/16", ORFS
|
