| 1. |
BN312043
|
[1] |
HOSE
|
BN
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel Elbow x 1/2" ID x 97" Long, Main Valve to LH Supplement Motor
|
| 2. |
BN312044
|
[1] |
HOSE
|
BN
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel Elbow x 1/2" ID x 115" Long, LH Supplement Motor to Main Valve
|
| 3. |
BN312045
|
[1] |
HOSE
|
BN
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel Elbow x 1/2" ID x 46" Long, Main Valve to Co-Ap Tube
|
| 4. |
BN309740
|
[1] |
HOSE
|
BN
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel Elbow x 1/2" ID x 100" Long, Main Valve to LH Co-Ap Motor
|
| 5. |
BN312046
|
[1] |
HOSE,123.00"
|
BN
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel Elbow x 1/2" ID x 123" Long, LH Co-Ap Motor to Main Valve
|
| 6. |
BN309742
|
[1] |
HOSE
|
TYR
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel Elbow x 1/2" ID x 43.5" Long, Main Valve to Supplemental Tube
|
| 7. |
BN309743
|
[1] |
HOSE,12.7mm ID x 533.4mm L
|
CUR
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel x 1/2" ID x 21" Long, RH Supplemental Motor to RH Co-Ap Motor
|
| 8. |
BN309744
|
[1] |
HOSE
|
BN
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel Elbow x 1/2" ID x 53" Long, Co-Ap Tube to RH Co-Ap Motor
|
| 9. |
BN309745
|
[1] |
HOSE
|
TYR
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel x 1/2" ID x 41" Long, Supplemental Tube to RH Supplemental Motor
|
| 10. |
87516546
|
[1] |
HOSE
|
BN
13/16-16 Female ORFS Swivel x 13/16-16 Female ORFS Swivel Elbow x 1/2" ID x 9" Long, RH Co-Ap Motor to Inline Check
|
| 11. |
87521320
|
[1] |
HOSE,228.60 mm
|
BN
13/16-16 Female ORFS Swivel x 1-3/16-16 Female ORFS Swivel Elbow x 1/2" ID x 9" Long, Inline Check to RH Conveyor Motor
|
| 12. |
BN302436
|
[1] |
TEE
|
BN
13/16 -16 ORFS x 13/16 -16 ORFS Swivel, Includes Ref 18
|
| 13. |
BN302438
|
[1] |
FITTING
|
BN
1-3/16"-16 ORFS x 1-3/16"-16 ORFS x 1-3/16"-16 ORB, Includes Ref 19
|
| 14. |
BN302651
|
[8] |
FITTING
|
BN
13/16-16 ORFS x 7/8-14 ORB, Includes Ref 18 and 20
|
| 15. |
129493A1
|
[1] |
FITTING
|
CAS
Inline Check Valve, 13/16"-16 ORFS x 13/16"-16 ORFS, Includes Ref 18 Superseded by part number: 235705A1
|
| 16. |
BN302650
|
[6] |
FITTING
|
BN
13/16 -16 ORFS x 3/4 -16 ORB, Includes Ref 18 and 21
|
| 17. |
BN65718
|
[4] |
HYDRAULIC MOTOR
|
BN
Co-Ap Bin
|
| 18. |
9992298
|
[16] |
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
|
BHB
13/16", ORFS
|
| 19. |
9991976
|
[11] |
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
|
WIN
1-3/16", ORFS
|
| 20. |
167269
|
[8] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
WIN
7/8", ORB
|
| 21. |
128825
|
[6] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
NH
3/4", ORB
|
