凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (36.100.02) - FAN GROUP, 6" CW Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
400 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN23813
|
[1] |
GASKET
|
BN
.060" Poly
|
| 2. |
BN35697
|
[1] |
HYDRAULIC MOTOR
|
BN
Blower Fan, .73 Cubic Inch
|
| . . |
BN35697R
|
[1] |
REMAN-HYD MOTOR
|
BN
810 (2/12-)
|
| . . |
BN35697C
|
[1] |
CORE-MOTOR HYDRAULIC
|
BN
Return Number
|
| 3. |
BN35698
|
[1] |
BUSHING
|
BN
Taper, 20 MM
|
| . . |
14723410
|
[1] |
KEY
|
COE
Not Shown, Used Between Ref 2 and Ref 3
|
| 4. |
87265706
|
[1] |
FAN
|
BN
High Pressure, 6", CW
|
| 5. |
BN50594
|
[2] |
BOLT,1/2"-13 x 1.75", Stainless
|
BN
|
| 6. |
BN50595
|
[2] |
WASHER,1/2", Stainless
|
BN
|
| 7. |
BN50697
|
[6] |
BOLT,Hex, 1/4" - 20 x 1/2", SST
|
BN
|
| 8. |
BN55363
|
[2] |
LOCK NUT,1/2"-13, Nylon, Stainless
|
BN
|
| 9. |
1020543
|
[1] |
SCREEN
|
CAS
Blower
|
| 10. |
1020540
|
[1] |
SCREEN
|
CAS
Cap
|
| 11. |
BN50769
|
[4] |
SCREW,Hex, #10 x 1/2"
|
BN
#10 X .5, HH, AB
|
| 12. |
BN50138
|
[6] |
WASHER,1/4", SS
|
BN
|
