凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (36.200.06) - SINGLE SOLENOID AIR VALVE, REAR SPRAYBAR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
238 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN301602
|
[1] |
VALVE
|
BN
Air, 12VDC, 2 Position, Complete, Includes Ref 2 - 7
|
| 2. |
BN307068
|
[1] |
COIL
|
BN
Pilot Assembly
|
| 3. |
87267590
|
[2] |
SCREW
|
BN
Pilot Housing
|
| 4. |
87267591
|
[2] |
SCREW
|
BN
Adapter Plate
|
| 5. |
87267592
|
[4] |
SCREW
|
BN
Retainer Mounting
|
| 6. |
BN307069
|
[1] |
SEAL KIT
|
BN
Solenoid
|
| 7. |
84269276
|
[1] |
SEAL
|
BN
Pressure, Pilot Valve
|
