凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (39.130.01) - INNER BOOM FOLD ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
698 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN10465
|
[12] |
NIPPLE, LUBE,1/4"-28 st
|
BN
NIPPLE
|
| 2. |
BN35642
|
[2] |
SUPPORT
|
BN
Boom Hinge
|
| 3. |
BN35722
|
[2] |
PIN
|
BN
Boom Hinge, Inner
|
| 4. |
BN35882
|
[1] |
SUPPORT
|
BN
RH Boom Hinge
|
| 5. |
BN35883
|
[1] |
SUPPORT
|
BN
LH Boom Hinge
|
| 6. |
343169A1
|
[4] |
SPACER
|
BN
Door Hinge, 14 GA
|
| . . |
BN35983
|
[6] |
SPACER
|
BN
Door Hinge, 7 GA
|
| . . |
BN35984
|
[3] |
SPACER
|
BN
Door Hinge, 10 GA
|
| . . |
BN35985
|
[4] |
SPACER
|
BN
Door Hinge, 12 GA
|
| 7. |
342683A1
|
[4] |
SPACER
|
BN
Boom, 14 GA
|
| . . |
BN35990
|
[3] |
SPACER
|
BN
Boom, 7 GA
|
| . . |
BN35991
|
[3] |
SPACER
|
BN
Boom, 10GA
|
| . . |
BN35992
|
[2] |
SPACER
|
BN
Boom, 12GA
|
| 8. |
BN50071
|
[2] |
NUT,1/2"-13, Stainless
|
BN
|
| 9. |
87310318
|
[2] |
JAM NUT
|
BN
5/8-11, JAM, G8, DOR
|
| 10. |
87698791
|
[2] |
WASHER,0.75" ID x 1.25" OD x 0.13" Thk
|
BRR
.750 X 1.250 X .1345, CST, DOR
|
| 11. |
87310424
|
[4] |
LOCK WASHER
|
BN
5/8 SPRING LK DOR
|
| 12. |
87342767
|
[2] |
BOLT
|
BN
3/8"-16 x 1-1/2", G5, Full Thd
|
| 13. |
87310193
|
[4] |
BOLT,3/4"-10 X 3.00", GR5, DOR
|
BN
|
| 14. |
87310192
|
[4] |
BOLT
|
BN
5/8"-11 x 4", G5
|
| 15. |
BN50600
|
[2] |
COTTER PIN
|
BN
3/16" X 1-1/2" Superseded by part number: 80754
|
| 16. |
BN50688
|
[14] |
BOLT,Hex, 1/4" - 20 x 1-1/4", SST
|
BN
1/4"-20 X 1-1/4", Stainless Steel
|
| 17. |
87310187
|
[10] |
BOLT
|
BN
3/8-16 X 7.5, G5, DOR
|
| 18. |
BN50759
|
[14] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 19. |
87310323
|
[4] |
NUT,3/4"-10, GR B, DOR
|
BN
|
| 20. |
BN55347
|
[2] |
BOLT
|
BN
1/2-13 X 3, Stainless Steel, Tap
|
| 21. |
BN55359
|
[14] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 22. |
87310611
|
[2] |
BOLT
|
BN
5/8-11 X 3, Gr 8, DOR
|
| 23. |
87528986
|
[4] |
WASHER,1.03" ID x 2" OD x 0.13" Thk
|
BN
1 1/32" x 2" x .134"
|
| 24. |
BN65724
|
[1] |
HINGE
|
TYR
RH Boom
|
| 25. |
BN65725
|
[1] |
HINGE
|
TYR
LH Boom
|
| 26. |
87266446
|
[2] |
HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 406.4mm Stroke
|
BN
Inner Boom Fold, 2.5 x 16 x 1.25, Complete
|
| 26. |
87266446R
|
[2] |
REMAN-HYD CYLINDER
|
BN
810 FLEX-AIR APPLICATOR, Inner Boom Fold, 2.5 x 16 x 1.25, Complete (2/12-)
|
| 26. |
87266446C
|
[2] |
CORE-HYD CYLINDER
|
BN
Return Number
|
| 27. |
BN69951
|
[12] |
CAP
|
BN
Grease
|
| 28. |
87310317
|
[4] |
NUT
|
BN
3/4-10, GR 8, DOR
|
| 29. |
BN23452
|
[2] |
WASHER,13/32" x 1.25 " OD x 12 GA, SS
|
BN
|
| 30. |
87310190
|
[2] |
BOLT
|
BN
3/8-16 X 6, G5, DOR
|
| 31. |
BN53802
|
[2] |
WASHER
|
BN
Beveled, 1/2"
|
