凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (39.130.06) - 60' BOOM, LH, INNER, 2-1/2" TUBES, BOOM LEVEL AND OUTER BOOM CRADLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
383 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN23267A
|
[1] |
SLIDER
|
BN
Nylatron .5 x 2.0 x 7.0
|
| 2. |
BN35892
|
[1] |
ARM
|
BN
Suspension
|
| 3. |
87310596
|
[2] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
BN
3/8", DOR
|
| 4. |
BN50146
|
[2] |
WASHER,3/8", Stainless
|
BN
|
| 5. |
BN50178
|
[2] |
WASHER
|
BN
1.25 OD X .75 ID X 10 GA
|
| 6. |
BN50254
|
[2] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 7. |
BN50258
|
[2] |
BOLT,3/8"-16 X 1.25", Stainless
|
BN
|
| 8. |
87310193
|
[1] |
BOLT,3/4"-10 X 3.00", GR5, DOR
|
BN
|
| 9. |
BN50759
|
[4] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 10. |
BN50930
|
[2] |
BOLT,5/16"-18 x 1.5", EH, DOR
|
BN
|
| 11. |
87310319
|
[1] |
JAM NUT,1"-14, G8
|
CUR
|
| 12. |
87310323
|
[2] |
NUT,3/4"-10, GR B, DOR
|
BN
|
| 13. |
BN55361
|
[2] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 14. |
87310197
|
[1] |
BOLT,3/4"-10 x 5", G5, DOR
|
BN
|
| 15. |
BN65473
|
[1] |
SUPPORT
|
BN
Boom Tip
|
| 16. |
87266447
|
[1] |
CYLINDER,Double Acting, 25.4mm Rod, 254mm Stroke
|
BN
Boom Tilt, 2.5 x 10 x 1, Complete
|
| 17. |
BN69278
|
[1] |
SUPPORT
|
BN
Tip-Over
|
| 18. |
BN69280
|
[1] |
SUPPORT
|
BN
Tip-Over
|
