现代零件查询R80-7 DOZER BLADE CYLINDER (#1389-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
168 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N1-40022
|
[1] |
DOZER CYLINDER ASSY
|
|
| 1. |
XKCD-03777
|
[1] |
TUBE ASSY
|
|
| 2. |
XKCD-01618
|
[1] |
PIN BUSH
|
|
| 3. |
XKCD-03778
|
[1] |
ROD ASSY
|
|
| 4. |
XKCD-01620
|
[1] |
PIN BUSH
|
|
| 5. |
XKCD-02258
|
[1] |
COVER-ROD
|
|
| 6. |
XKCD-01193
|
[1] |
BUSHING-ROD
|
|
| 7. |
XKCD-01194
|
[1] |
RING-RETAINING
|
|
| K8. |
XKCD-02482
|
[1] |
BUFFER SEAL
|
|
| K9. |
XKCD-03779
|
[1] |
U-PACKING
|
|
| K10. |
XKCD-01126
|
[1] |
RING-BACK UP
|
|
| K11. |
XKCD-01127
|
[1] |
WIPER-DUST
|
|
| 12. |
XKCD-01624
|
[1] |
RING-RETAINING
|
|
| K13. |
XKCD-01253
|
[1] |
O-RING
|
|
| K14. |
XKCD-01254
|
[1] |
RING-BACK UP
|
|
| K15. |
XKCD-00555
|
[1] |
O-RING
|
|
| 16. |
XKCD-01625
|
[1] |
PISTON
|
|
| K17. |
XKCD-01017
|
[1] |
SEAL-PISTON
|
|
| K18. |
XKCD-01626
|
[1] |
WEAR RING
|
|
| K19. |
XKCD-01019
|
[1] |
RING-DUST
|
|
| K20. |
XKCD-01272
|
[1] |
O-RING
|
|
| 21. |
XKCD-02284
|
[1] |
NUT-PISTON
|
|
| 22. |
XKCD-01205
|
[1] |
SCREW-SET
|
|
| 23. |
XKCD-02526
|
[1] |
SPACER
|
|
| K24. |
XKCD-00454
|
[1] |
O-RING
|
|
| 25. |
XKCD-01629
|
[2] |
HEX SOCKET BOLT
|
|
| 26. |
XKCD-02527
|
[1] |
VALVE-CHECK
|
|
| K27. |
XKCD-01207
|
[1] |
O-RING
|
|
| 28. |
XKCD-01210
|
[2] |
BOLT-SOCKET
|
|
| 29. |
XKCD-01630
|
[2] |
HEX SOCKET BOLT
|
|
| 30. |
XKCD-01632
|
[1] |
PIPE ASSY
|
|
| K31. |
XKCD-01207
|
[1] |
O-RING
|
|
| 32. |
XKCD-01212
|
[4] |
BOLT-SOCKET
|
|
| 33. |
XKCD-00989
|
[4] |
WASHER-SPRING
|
|
| 34. |
XKCD-01047
|
[1] |
NIPPLE-GREASE
|
|
| 35. |
XKCD-01024
|
[1] |
NIPPLE-GREASE
|
|
| K36. |
XKCD-01213
|
[4] |
WIPER-PIN
|
|
| K. |
XKCD-03780
|
[1] |
SEAL KIT
|
|
