凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (39.130.16) - 60' BOOM, RH, INNER, 3" TUBES, BOOM LEVEL AND OUTER BOOM CRADLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
580 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN23267A
|
[1] |
SLIDER
|
BN
Nylatron .5 x 2.0 x 7.0
|
| 2. |
87266447
|
[1] |
CYLINDER,Double Acting, 25.4mm Rod, 254mm Stroke
|
BN
Boom Tilt, 2.5 x 10 x 1, Complete
|
| 3. |
BN35892
|
[1] |
ARM
|
BN
Suspension
|
| 4. |
BN50142
|
[2] |
WASHER,5/16", Stainless Steel
|
BN
|
| 5. |
87528981
|
[2] |
WASHER,0.81" ID x 1.5" OD x 0.14" Thk
|
BN
|
| 6. |
BN50254
|
[2] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 7. |
87310193
|
[1] |
BOLT,3/4"-10 X 3.00", GR5, DOR
|
BN
|
| 8. |
BN50759
|
[2] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 9. |
BN50930
|
[2] |
BOLT,5/16"-18 x 1.5", EH, DOR
|
BN
|
| 10. |
87310319
|
[1] |
JAM NUT,1"-14, G8
|
CUR
|
| 11. |
87310323
|
[2] |
NUT,3/4"-10, GR B, DOR
|
BN
|
| 12. |
BN55361
|
[2] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 13. |
87310197
|
[1] |
BOLT,3/4"-10 x 5", G5, DOR
|
BN
|
| 14. |
BN65473
|
[1] |
SUPPORT
|
BN
Boom Tip
|
| 15. |
BN68662
|
[1] |
BASE
|
BN
Boom Tip Support
|
| 16. |
BN68663
|
[1] |
SUPPORT
|
TYR
Boom Tip
|
