凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (39.130.23) - 70' BOOM, RH, INNER, 2-1/2" TUBES, BOOM LEVEL AND OUTER BOOM CRADLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
624 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN10057
|
[1] |
LUBE NIPPLE,1/4"-28 x 90
|
BN
|
| 2. |
BN69951
|
[1] |
CAP
|
BN
Grease
|
| 3. |
BN315368
|
[1] |
SLIDE
|
BN
.19 X 6.25 X 4.13
|
| 4. |
84512688
|
[1] |
ARM
|
BN
Suspension, 70'
|
| 5. |
87310596
|
[4] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
BN
3/8", DOR
|
| 6. |
BN50146
|
[2] |
WASHER,3/8", Stainless
|
BN
|
| 7. |
87528981
|
[2] |
WASHER,0.81" ID x 1.5" OD x 0.14" Thk
|
BN
|
| 8. |
BN50254
|
[4] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 9. |
87310193
|
[1] |
BOLT,3/4"-10 X 3.00", GR5, DOR
|
BN
|
| 10. |
BN50759
|
[4] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 11. |
BN50779
|
[4] |
BOLT,5/16"-18 X 1.00", EH, DOR
|
BN
|
| 12. |
87310319
|
[1] |
JAM NUT,1"-14, G8
|
CUR
|
| 13. |
87310323
|
[2] |
NUT,3/4"-10, GR B, DOR
|
BN
|
| 14. |
BN55361
|
[4] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 15. |
87310197
|
[1] |
BOLT,3/4"-10 x 5", G5, DOR
|
BN
|
| 16. |
87266447
|
[1] |
CYLINDER,Double Acting, 25.4mm Rod, 254mm Stroke
|
BN
Boom Tilt, 2.5 x 10 x 1, Complete
|
| 17. |
BN315304
|
[1] |
SUPPORT
|
TYR
Tip-over, 70'
|
