神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (02-003) - PLATE ASSY, FLOOR - 24100J13289F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
128 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J13289F1 | [1] | PLATE ASSY, FLOOR | |
| 1. | 2427J2930 | [1] | PLATE, FLOOR | |
| 2. | 2414T2855 | [8] | COVER | KOB |
| 3. | 2416Z539 | [8] | RUBBER SLEEVE | KOB |
| 4. | 2418T9226D7 | [4] | SPACER | KOB |
| 5. | ZS18C16100 | [4] | SCREW,Hex, M16 x 100mm | KOBM16x2.0x100mm |
| 6. | ZN32C16015 | [4] | NUT | KOBM16x2.0mm, Serial Range: LLU00301-LLU00383 |
| . . | ZN18C16013 | [4] | NUT | KOBM16x2.0mm, Start Serial: LLU00384 |
| 7. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 8. | 2479Z1919 | [1] | INSULATOR | KOB |
| 9. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 10. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 11. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 12. | 2427U1431 | [1] | FLOOR MAT | KOB Superseded by part number: 2427U1478 |
| 13. | 2429P576D2 | [1] | STEP | KOB |
| 14. | 2429P576D1 | [1] | STEP | KOB |
| 15. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 16. | 2427Z1529 | [2] | RUBBER SLEEVE | KOB |
| 17. | 2418T19170 | [1] | PLATE | KOB |
| 18. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 19. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 20. | 2420Z1339 | [1] | GROMMET | KOB |
| 21. | 2420Z1286 | [1] | GROMMET | KOBGROMMET PLUG |
| 22. | 2418Z740 | [4] | RUBBER RING | KOB |
| 23. | 2427U900 | [1] | TANK | KOBWASHER |
| 24. | 2416T22805 | [1] | SUPPORT | SUPPORT |
| 25. | 2420Z1374 | [7] | PLUG | KOB |
| 26. | 2420Z1330 | [1] | GROMMET | KOB |
| 27. | 2414T2880 | [1] | COVER | KOB |
| 28. | 2414T2879 | [1] | COVER | KOB |
| 29. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 30. | 2405T1749 | [1] | BUSHING | KOBBUSHING |
| 35. | 2420Z1617 | [1] | PLUG | KOBPLUG |
