神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (17-024) - WATER PIPE & THERMOSTAT - 030-120D Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
707 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-2. | VAME070153 | [1] | CASE | KOBTHERMOSTAT Superseded by part number: VAME047992 |
| 1. | VAME070154 | [1] | PLASTIC CASE | KOBTHERMOSTAT Superseded by part number: VAME047993 |
| 2. | VAME035254 | [1] | UNIVERSAL JOINT | KOBBY-PASS |
| 3-4. | VAME999463 | [1] | THERMOSTAT | KOB76.5C Superseded by part number: 77278300, VAME994514 |
| 3. | VAME035100 | [1] | GASKET | KOB Superseded by part number: VAME303375 |
| 4. | VAME035320 | [1] | THERMOSTAT 76.5C | THERMOSTAT 76.5C |
| 5. | VAME035098 | [1] | COVER | KOBTHERMOSTAT |
| 6. | VAMF140227 | [3] | FLANGE BOLT | KOBBOLT, FLANGE 8X25 |
| 7. | VA3124618702 | [2] | PLUG | KOBPLUG Superseded by part number: 240292A1 |
| 7A. | VAM0001300 | [1] | PLUG | KOBPLUG 16 |
| . . | VAMF660066 | [1] | GASKET | KOBGASKET 16 Superseded by part number: VAF420216000 |
| 8. | VAME031082 | [1] | GASKET | KOBHANGER Superseded by part number: VAME074770 |
| 9. | VAMH000517 | [2] | BOLT | KOBBOLT, SEAL 10X30 |
| . . | VAMH000537 | [2] | BOLT | KOBBOLT, SEAL 10X105 |
