凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (55.515.01) - OUTER BOOM FOLD POSITION SENSOR, 70' BOOM, LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
358 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN50212
|
[2] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 2. |
BN318242
|
[1] |
BRACKET
|
BN
Magnet Sensor, LH
|
| 3. |
BN315498
|
[1] |
SWITCH
|
BN
Proximity Sensor, With Diode
|
| 4. |
BN55359
|
[2] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 5. |
BN318447
|
[1] |
WIRE HARNESS
|
BN
LH Boom Switch
|
| 6. |
87266009
|
[2] |
BOLT
|
BN
M6-1 x 16, Stainless Steel
|
| 7. |
86980513
|
[2] |
NUT,Prev Torque, Hex, M6, 1mm Pitch, Cl 8, DOR
|
BN
|
| 8. |
BN50138
|
[4] |
WASHER,1/4", SS
|
BN
|
