凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.110.01.AA) - MAIN BIN MOUNT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
218 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87310604
|
[4] |
BOLT,Hex, M20 x 120mm, Cl 10.9
|
BN
M20-2.5 x 120, 10.9, DOR
|
| 2. |
87310608
|
[16] |
WASHER,22mm ID x 44mm OD x 5mm Thk
|
BN
22 x 44 x 5 mm, HDN, DOR
|
| 3. |
86986163
|
[4] |
SPACER
|
BN
Rear Mount
|
| 4. |
87024336
|
[8] |
NUT,M20 x 2.5, Cl 10
|
GI
|
| 5. |
87266921
|
[2] |
SLIDE
|
BN
Body Mount
|
| 6. |
87594367
|
[4] |
SPACER
|
BN
|
| 7. |
BN50779
|
[6] |
BOLT,5/16"-18 X 1.00", EH, DOR
|
BN
|
| 8. |
BN312850
|
[4] |
SPRING
|
BN
1" ID x 4" Lg-Die
|
| 9. |
BN50142
|
[6] |
WASHER,5/16", Stainless Steel
|
BN
|
| 10. |
87343954
|
[4] |
NUT
|
CUR
Hex, 5/8"-11, GC
|
| 11. |
87310650
|
[8] |
WASHER,0.66" ID x 1.31" OD x 0.15" Thk
|
BN
.656 x 1.312 x .150, HTS, DOR
|
| 12. |
87310421
|
[4] |
BOLT
|
BN
5/8-11 X 2.5, G8, DOR
|
| 13. |
BN313867
|
[2] |
BELT,4.00" W x 153.00" L
|
BN
|
| 14. |
BN55361
|
[6] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 15. |
87594365
|
[2] |
SPACER
|
BN
Rear Mount, Flex-Air
|
| 16. |
87310605
|
[4] |
BOLT,M20 x 180, 10.9, DOR
|
BN
|
