| 1. |
47697228
|
[6] |
HINGE
|
BN
Co-Ap Bin
|
| 2. |
BN306380
|
[2] |
HINGE
|
BN
3/4" Rod, Co-Ap Bin
|
| 3. |
84185176
|
[1] |
BRACKET
|
BN
Center Co-Ap Support Superseded by part number: 84188692, 84187133, 87342769, 87343970, 87529237
|
| 4. |
BN309338
|
[2] |
PIN
|
BN
5/8" With Shoulder
|
| 5. |
BN309339
|
[2] |
BAR
|
BN
Latch, Long
|
| 6. |
BN309340
|
[2] |
BAR
|
BN
Latch, Short
|
| 7. |
BN309409
|
[4] |
BUMPER
|
BN
2" DIA x 1-5/8", Neoprene
|
| 8. |
BN309410
|
[4] |
BUMPER
|
BN
3/4-10, Threaded Rod
|
| 9. |
BN309412
|
[8] |
WASHER,3/4, Stainless Steel
|
BN
|
| 10. |
BN309413
|
[4] |
SCREW,3/4" - 10, SST
|
BN
3/4-10, Stainless Steel
|
| 11. |
BN309886
|
[2] |
COVER
|
BN
Auxiliary Auger Hole
|
| 12. |
BN309887
|
[1] |
COVER
|
BN
Sensor Hole
|
| 13. |
BN310661
|
[2] |
CABLE
|
BN
Co-Ap Bin Tip
|
| 14. |
BN71007
|
[4] |
CLIP,3/16" Hairpin
|
BN
Hairpin, 3/16" #8
|
| 15. |
BN55373
|
[12] |
BOLT,3/8"-16 X 3-1/2", Stainless Steel
|
BN
|
| 16. |
BN50142
|
[16] |
WASHER,5/16", Stainless Steel
|
BN
|
| 17. |
BN50146
|
[24] |
WASHER,3/8", Stainless
|
BN
|
| 18. |
BN50267
|
[4] |
BOLT,3/8"-16 x 2", Stainless Steel
|
BN
|
| 19. |
BN50476
|
[20] |
BOLT,5/16"-18 x 0.75", Stainless
|
BN
|
| 20. |
BN50593
|
[4] |
BOLT,1/2"-13 x 1-1/2", Stainless Steel
|
BN
|
| 21. |
BN50595
|
[8] |
WASHER,1/2", Stainless
|
BN
|
| 22. |
BN50600
|
[4] |
COTTER PIN
|
BN
3/16" X 1-1/2" Superseded by part number: 80754
|
| 23. |
BN50661
|
[8] |
NUT,3/4"-10, Stainless Steel
|
BN
|
| 24. |
BN50679
|
[4] |
BOLT,1/2-13 X 1.25", Stainless
|
BN
|
| 25. |
BN50759
|
[16] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 26. |
BN52033
|
[4] |
BOLT,1/4"-20 X 5/8", Stainless Steel
|
BN
|
| 27. |
BN55359
|
[4] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 28. |
BN55361
|
[20] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 29. |
BN55363
|
[8] |
LOCK NUT,1/2"-13, Nylon, Stainless
|
BN
|
| 30. |
BN55365
|
[2] |
LOCK NUT,5/8"-11, Nylon, Stainless
|
BN
|
| 31. |
BN55347
|
[4] |
BOLT
|
BN
1/2 x 13 x 3, HH, SS TAP, NOT SHOWN
|
| 32. |
BN50071
|
[8] |
NUT,1/2"-13, Stainless
|
BN
NOT SHOWN
|
