神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (07-002) - IDLER ASSY - 24100J11697F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
296 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J11697F1 | [1] | IDLER WHEEL | KOB Superseded by part number: 24100J11697F2 |
| 1. | 2413N450 | [1] | IDLER | KOB Superseded by part number: 24100J12445F1 |
| 2. | 2405P482 | [2] | BUSHING | KOBID 75.2 x OD 83 x 69.5mm Long |
| 3. | 2413N394 | [2] | SLIDE VALVE | KOB |
| 4. | R45P0018D13 | [2] | SEAL | KOB Superseded by part number: ZD57F11032 |
| 5. | 2419T2668D2 | [2] | PIN | KOB Superseded by part number: 2419T6351 |
| 6. | 2410P791 | [1] | ROLLER SHAFT | KOB |
| 7. | ZD11G07000 | [2] | O-RING,69.40mm ID x 75.60mm OD x 3.10mm | KOBID 69.40 ± 0.61 x OD 75mm |
| 8. | ZE82T02000 | [2] | PLUG | KOBPipe, 1.25" PT |
