神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (07-005) - SPRING ASSY, TRACK - 24100N6548F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
670 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N6548F1 | [1] | SHOCK ABSORBER | KOB |
| 1. | 2438N265 | [1] | CYLINDER | KOB |
| 2. | 2416N5829 | [1] | SHOCK ABSORBER | KOB Superseded by part number: 2416N5878 |
| 3. | 2420T7404 | [1] | NUT | KOBCap -- M56x3.0mm |
| 4. | ZP26D08080 | [1] | PIN | KOBRoll -- OD 08 x 80mm Long |
| 5. | 2417P274 | [1] | SPRING | KOB |
| 6. | ZS13C20050 | [2] | SCREW | KOBM20x2.50x50mm |
| 7. | 2444P803 | [1] | LUBE NIPPLE,5/8" - 18 x 64mm L, 19mm Hex | KOB5/8" - 18 UNF, Straight |
| 8. | 2439P174 | [1] | PISTON | KOB |
| 9. | 2445Z1034 | [1] | GASKET,90mm ID x 105mm OD x 10mm Thk | KOBSEAL, OIL |
| 10. | ZD12G09000 | [1] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOBID 89.40 ± 0.77 x OD 95mm |
| 11. | 2418T21468 | [1] | COLLAR CLAMP | KOB Superseded by part number: 2418T21652 |
| 12. | 2419T4748 | [2] | PIN | KOB Superseded by part number: LQ54D01023P1 |
