凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.110.03.EF) - TRIPLE BIN, RH, WITH AUGER, 37 CUBIC FOOT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
835 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN21398A
|
[2] |
COUPLING
|
BN
Machined
|
| 2. |
BN22884
|
[2] |
KIT
|
BN
Adaptor
|
| 3. |
BN314948
|
[2] |
SENSOR
|
BN
Application Rate
|
| 4. |
86986421
|
[1] |
BRACKET
|
BN
Sensor Control
|
| 5. |
BN71007
|
[2] |
CLIP,3/16" Hairpin
|
BN
Hairpin, 3/16" #8
|
| 6. |
BN30283
|
[2] |
STOP
|
BN
1/4 SQ. Keystock x 1
|
| 7. |
BN307047
|
[2] |
PIN
|
BN
3/8, With Shoulder
|
| 8. |
342478A1
|
[2] |
LATCH
|
BN
Swell
|
| 9. |
BN308143
|
[1] |
COVER
|
BN
Wind, RH
|
| 10. |
BN308146
|
[1] |
COVER
|
BN
Lower Co-Ap
|
| 11. |
BN308147
|
[2] |
PIN
|
BN
Lower Co-Ap Cover Pivot
|
| 12. |
86986418
|
[1] |
COVER
|
BN
RH Bin Auger
|
| 13. |
BN309337
|
[2] |
LATCH
|
BN
Flexible Draw
|
| 14. |
BN312519
|
[2] |
SENSOR
|
BN
Bracket, Rate
|
| 15. |
BN67438
|
[1] |
SEAL
|
BN
Weather Strip, Wind Cover
|
| 16. |
BN310264
|
[10] |
SCREW,#10 - 24 x 1 1/4", SST
|
BN
10-24 X 1-1/4", BSH, SS
|
| 17. |
BN310265
|
[10] |
WASHER
|
BN
10, Stainless Steel
|
| 18. |
BN310266
|
[10] |
BHD LOCK NUT,#10-24, Nylon, Stainless Steel
|
BN
|
| 19. |
BN310644
|
[2] |
MOUNTING PLATE
|
BN
Bin Lights
|
| 20. |
BN310648
|
[2] |
LIGHT
|
BN
Co-Ap Bin
|
| 21. |
87265980
|
[1] |
WINDOW
|
BN
Hopper 12" x 8"
|
| 22. |
BN35938
|
[1] |
ARM
|
BN
Torque, RH Co-Ap
|
| 23. |
BN35939
|
[1] |
ARM
|
BN
Torque, LH Co-Ap
|
| 24. |
BN50250
|
[8] |
BOLT,3/8"-16 x 3/4", Stainless Steel
|
BN
Superseded by part number: 113-2299
|
| 25. |
BN50254
|
[4] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 26. |
BN50421
|
[2] |
SET SCREW
|
BN
5/16"-18 X 1/2"
|
| 27. |
BN50473
|
[2] |
SET SCREW
|
BN
5/16"-18 X 3/4"
|
| 28. |
BN50697
|
[6] |
BOLT,Hex, 1/4" - 20 x 1/2", SST
|
BN
|
| 29. |
BN50759
|
[6] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 30. |
BN55359
|
[6] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 31. |
BN65718
|
[2] |
HYDRAULIC MOTOR
|
BN
Co-Ap Bin
|
