| 1. |
BN10054
|
[4] |
COLLAR
|
BN
1-1/4" OD x 3/4" ID, HRST
|
| 2. |
BN23452
|
[2] |
WASHER,13/32" x 1.25 " OD x 12 GA, SS
|
BN
|
| 3. |
BN307047
|
[2] |
PIN
|
BN
3/8, With Shoulder
|
| 4. |
BN308142
|
[1] |
BRACKET, SUPPORTING
|
TYR
Supplemental
|
| 5. |
BN309317
|
[1] |
PANEL
|
BN
Supplemental Access
|
| 6. |
BN310862
|
[2] |
WASHER
|
BN
Co-Ap Bin
|
| 7. |
BN310283
|
[2] |
PIN
|
BN
3/8, With 3/4 Shoulder
|
| 8. |
BN35411
|
[2] |
HANDLE
|
TYR
Bin Gate Adjust
|
| 9. |
BN35705
|
[1] |
BEARING HOUSING
|
BN
Co-Ap Wheel Housing, LH
|
| 10. |
BN35706
|
[1] |
BEARING HOUSING
|
BN
Co-Ap Wheel Housing, RH
|
| 11. |
BN35707
|
[2] |
BEARING CAP
|
BN
Valmar - Latch, Stainless Steel
|
| 12. |
BN35785
|
[2] |
SLIDE
|
BN
Vertical, Co-Ap Gate
|
| 13. |
BN35786
|
[4] |
LINK
|
BN
Co-Ap Bin Gate
|
| 14. |
BN35787
|
[1] |
GATE ASSY
|
BN
Co-Ap Bin
|
| 15. |
BN35788
|
[2] |
SEAL
|
BN
Co-Ap Gates
|
| 16. |
BN35789
|
[1] |
SEAL
|
BN
Co-Ap Gates
|
| 17. |
BN35790
|
[1] |
COVER
|
BN
Co-Ap Bin Gate
|
| 18. |
BN35791
|
[1] |
SLIDE
|
BN
Horizontal, Co-Ap Gate
|
| 19. |
BN35793
|
[1] |
GATE ASSY
|
BN
Supplemental Bin
|
| 20. |
BN35796
|
[2] |
SHAFT
|
BN
Supplemental Gate
|
| 21. |
BN35799
|
[4] |
LINKAGE
|
BN
Supplemental Gate
|
| 22. |
BN35800
|
[4] |
BUSHING
|
BN
Shaft, Supplemental Gate
|
| 23. |
BN35801
|
[4] |
SEAL
|
BN
Shaft, Supplemental Gate
|
| 24. |
BN50142
|
[8] |
WASHER,5/16", Stainless Steel
|
BN
|
| 25. |
BN50232
|
[16] |
BOLT,5/16"-18 x 1.00", Stainless Steel
|
BN
|
| 26. |
BN50254
|
[2] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 27. |
BN50258
|
[2] |
BOLT,3/8"-16 X 1.25", Stainless
|
BN
|
| 28. |
BN50421
|
[8] |
SET SCREW
|
BN
5/16"-18 X 1/2"
|
| 29. |
BN50671
|
[34] |
BOLT,1/4"-20 x 1.00", Stainless Steel
|
BN
|
| 30. |
BN50759
|
[8] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 31. |
87343659
|
[12] |
SELF-TAP SCREW,Hex Wshr, 1/4" - 20 x 3/4"
|
BN
Tapping, 1/4"-20 x 3/4"
|
| 32. |
84204175
|
[4] |
SLOTTED PIN
|
BN
5/32 X 1-1/2, SS
|
| 33. |
BN55359
|
[34] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 34. |
BN55361
|
[16] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 35. |
BN65711
|
[2] |
CAP
|
BN
Lever, 1.25 X .162 X 4.00
|
| 36. |
BN71007
|
[2] |
CLIP,3/16" Hairpin
|
BN
Hairpin, 3/16" #8
|
