| . . | 24100J6436F1 | [1] | CAB ASSY CAB ASSY, Serial Range: YC-0101-YC-0143 | CAB ASSY CAB ASSY, Serial Range: YC-0101-YC-0143 |
| . . | 24100J6436F2 | [1] | CAB ASSY YC-0144 to | |
| 1. | 2427U598 | [1] | CAB ASSY, Serial Range: YC-0101-YV-0143 | |
| 2. | 2427U598D2 | [1] | CAB ASSY, Start Serial: YV-0144 | |
| 5. | 24100J6436S5 | [1] | DOOR DOOR ASSY | DOOR DOOR ASSY |
| 6. | 24100N2819F1 | [1] | WINDOW | KOBSASH |
| 6-1. | 24100N2819S1 | [1] | FRAME ASSY FRAME ASSY | FRAME ASSY FRAME ASSY |
| 6-2. | 2427T850 | [1] | GLASS | KOBGLASS |
| 6-3. | 2427T848 | [1] | GLASS | KOB |
| 6-4. | 2427T851 | [1] | GLASS | KOB |
| 6-5. | 24100N2819S2 | [1] | LOCK | LOCK |
| 6-6. | 24100N2819S3 | [1] | LOCK LOCK | LOCK LOCK |
| 6-7. | 24100N2819S4 | [1] | GUIDE | KOBGUIDE |
| 6-8. | 24100N2819S5 | [1] | WEATHERSTRIP | KOBSTRIP, WEATHER |
| 6-9. | 24100N2819S6 | [1] | SEAL | KOBSEAL |
| 6-10. | 24100N2819S7 | [1] | RUBBER | |
| 6-11. | 24100N2819S8 | [1] | RUBBER SLEEVE | KOB |
| 6-12. | 24100N2819S9 | [1] | RUBBER | |
| 8. | 2408P502 | [1] | HOOK | KOBHANDLE ASSY |
| 9. | 24100J6284S9 | [2] | CAPSCREW | |
| 10. | 2406R234 | [1] | HANDLE | KOBHANDLE |
| 11. | 24100J6436S11 | [2] | SCREW | KOBMACHINE SCREW |
| 12. | 2414T2024 | [1] | COVER | KOBCOVER |
| 13. | ZS31C05016 | [2] | BOLT,Phillips Drive, Pan HD, M5 x 16mm | KOBM05x0.8x16mm |
| 14. | 2406R220 | [1] | HANDLE | KOBHANDLE ASSY |
| 14-2. | 2406R220S2 | [1] | KEY | KOBKEY |
| 15. | ZS41C05014 | [2] | SCREW,M5 x 14mm | KOBM05x0.8x14mm |
| 16. | 2406R221 | [1] | HANDLE | KOBHANDLE, INSIDE |
| 17. | 2414T2006 | [1] | COVER | KOBCOVER |
| 18. | 2421Z285 | [1] | LH DOOR LOCK | KOBLOCK ASSY, DOOR |
| 19. | 24100J6107S110 | [4] | SCREW | KOB |
| 20. | 2416Z220D8 | [1] | SOFT TRIM | KOBSEAL, RUBBER |
| 21. | 2414T2005 | [1] | GUARD | |
| 22. | 2420Z990 | [3] | RIVET | |
| 23. | 2416Z472D11 | [1] | STRIP, WEATHER | |
| 25. | 24100J6284S25 | [6] | CAPSCREW | CAPSCREW |
| 26. | 2427R656 | [1] | PAD | PAD |
| 27. | 24100J6436S27 | [2] | SEAL | KOBTOOL |
| 28. | 24100J6436S28 | [1] | CAPACITOR | CAPACITOR |
| 29. | 24100J6436S29 | [2] | SETSCREW | |
| 30. | 24100J6436S30 | [1] | BRACKET, ROOM LIGHT | |
| 31. | 24100J6107S34 | [2] | SCREW | KOBSETSCREW Superseded by part number: ZM41C06012 |
| 32. | 2427P1836 | [1] | WEATHERSTRIP | KOB |
| 33. | 2427R658 | [1] | PAD | KOB |
| 34. | 2418Z712 | [11] | WASHER | KOB |
| 35. | 24100J6107S83 | [11] | BOLT | BOLT |
| 39. | 2427Z534 | [1] | LH DOOR LOCK | KOBCRESCENT |
| 43. | 2427Z553 | [1] | GLASS | HITGLASS |
| 44. | 24100J6436S44 | [1] | RUBBER SLEEVE | KOBRUBBER |
| 45. | 2427R626 | [1] | ASH TRAY | KOBTRAY, ASH |
| 46. | 24100J6107S104 | [2] | SCREW | KOBMACHINE SCREW |
| 47. | 2427Z556 | [1] | PAD | |
| 43. | 2427R660 | [1] | PAD | |
| 49. | 2427R661 | [1] | PAD | |
| 52. | 2479U255 | [1] | ANTENNA | KOBANTENNA |
| 53. | 24100P1638F1 | [1] | WASHER | KOB |
| 53-2. | 2418Z633 | [1] | TUBE | KOBTUBE |
| 53-3. | 24100R43 | [1] | NOZZLE | KOBNOZZLE ASSY |
| 53-4. | 24100Z37 | [1] | NOZZLE | KOBNOZZLE ASSY |
| 53-8. | 24100J6107S138 | [1] | GROMMET | GROMMET |
| 53-9. | 2432Z309D1 | [5] | CLAMP | KOBCLIP |
| 54. | 24100J6107S138 | [1] | GROMMET GROMMET | GROMMET GROMMET |
| 55. | 2432Z309D1 | [5] | CLAMP | KOBCLAMP, HARNESS |
| 56. | 2420Z1030D2 | [2] | KIT | KOBKEY Superseded by part number: PM50S01001P1 |
| 57. | 2427R478 | [1] | PAD | |
| 60. | 2427Z554 | [1] | GLASS | KOBGLASS |
| 61. | 24100J6436S61 | [1] | STRIP, WEATHER | |
| 64. | 24100J6284S64 | [1] | BRACKET | BRACKET |
| 65. | 2414P2613 | [1] | COVER | KOB |
| 66. | 24100J6284S66 | [3] | CAPSCREW | |
| 67. | 2427T854 | [1] | ROD | KOBROD |
| 68. | ZP15K02012 | [1] | COTTER PIN | KOBSPLIT PIN Superseded by part number: ZP15K02035 |
| 69. | ZX15K06062 | [1] | TUBE, NYLON | |
| 70. | 2406Z194 | [1] | GRIP | KOBGRIP |
| 71. | ZN16C05004 | [1] | NUT | KOBM05x0.8mm Superseded by part number: ZN18C05004 |
| 72. | 2427R663 | [1] | RAIL, HAND | |
| 73. | 24100J6107S70 | [2] | SCREW | KOBCAPSCREW |
| 74. | 2406R243 | [1] | RAIL, HAND RAIL, HAND | RAIL, HAND RAIL, HAND |
| 75. | 24100J6284S75 | [4] | SCREW | KOB |
| 76. | 2408T302 | [1] | HOOK | |
| 78. | 2427Z510 | [2] | STOP | KOBSTOPPER |
| 79. | ZN16F10008 | [2] | NUT | KOBNUT Superseded by part number: ZN18F10008 |
| 80. | 2427R662 | [1] | PAD | |
| 81. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 82. | 2427Z538 | [2] | BRACKET | KOBBRACKET, LATCH |
| 83. | 2414Z272 | [2] | COVER | KOBCOVER |
| 84. | 2416Z465 | [2] | STOP | KOBSTOPPER, RUBBER |
| 85. | 24100J6107S117 | [4] | BOLT, SET BOLT, SET | BOLT, SET BOLT, SET |
| 86. | 24100J6436S86 | [1] | COVER | |
| 87. | 24100J6436S87 | [1] | COVER | |
| 88. | 2427R657F1 | [1] | GLASS, WINDOW SASH ASSY | GLASS, WINDOW SASH ASSY |
| 88-1. | 2427R657S1 | [1] | SASH | |
| 88-2. | 2427Z555 | [1] | GLASS | KOBGLASS |
| 88-3. | 2427R657S3 | [1] | CHANNEL CHANNEL | CHANNEL CHANNEL |
| 88-4. | 2427R657S4 | [1] | LOCK | KOBLOCK Superseded by part number: 24100R164S4 |
| 88-5. | 2427R657S5 | [1] | LOCK LOCK | LOCK LOCK |
| 88-6. | 2427R657S6 | [1] | SPACER | KOBSPACER |
| 88-7. | 2427R657S7 | [1] | STRIKER PLATE | KOBSTRIKER |
| 88-8. | 2427R657S8 | [1] | STRIKER PLATE | KOBSTRIKER |
| 88-9. | 2427R657S9 | [1] | SEAL | |
| 88-10. | 2427R657S10 | [1] | WEATHERSTRIP | KOBSTRIP, WEATHER |
| 88-11. | 2427R657S11 | [1] | SEAL | |
| 88-12. | 2427R657S12 | [1] | PLATE | |
| 89. | 2416Z472D13 | [1] | STRIP, WEATHER | |
| 90. | 2427R659 | [1] | PAD | |
| 91. | 24100J6436S91 | [1] | GLASS | KOBGLASS |
| 92. | 24100J6436S92 | [1] | RUBBER | |
| 94. | 24100J6436S94 | [2] | COVER | KOBCOVER |
| 95. | 24100J6436S95 | [4] | BOLT | KOBBOLT Superseded by part number: 24100J6512S220 |
| 96. | 24100J6107S162 | [4] | LOCK WASHER | KOBWASHER Superseded by part number: ZW16X08000 |
| 97. | 24100J6107S161 | [4] | LOCK WASHER | KOBLOCK WASHER Superseded by part number: 83990583 |
| 99. | 2427U318 | [1] | FRAME | KOBWINDOW, FR. |
| 99-11. | ZR36X00800 | [5] | SNAP RING | KOBCLIP |
| 99-12. | 2425Z508 | [4] | BALL BEARING | KOBBEARING, BALL Superseded by part number: 2425Z8 |
| 100. | 24100J6436S100 | [1] | GLASS | KOBGLASS |
| 101. | 2416Z472D5 | [1] | RUBBER STRIP, WEATHER | RUBBER STRIP, WEATHER |
| 102. | 2479R704 | [1] | WIPER | KOBMOTOR, WIPER Superseded by part number: YT53C00011F1 |
| 103. | 24100J6436S103 | [1] | TOOL | |
| 104. | 2479R703 | [1] | WIPER ARM | KOBARM, WIPER Superseded by part number: 2488R249 |
| 105. | R79P0021D2 | [1] | WIPER BLADE | KOBELADE, WIPER Superseded by part number: 2488Z8D4 |
| 106. | 24100J6436S106 | [1] | WIRE HARNESS | KOBHARNESS |
| 107. | 24100J6436S107 | [2] | STOP | KOBRUBBER Superseded by part number: 24100J6512S130, PY06C01040P1 |
| 108. | 24100J6436S108 | [2] | NUT | KOB |
| 109. | 2416Z471D2 | [1] | RUBBER SLEEVE | KOBRUBBER |
| 110. | 2427T863 | [1] | PLATE | KOB |
| 112. | 2416P7231 | [1] | STAY | KOBSTAY |
| 113. | ZW16X16000 | [1] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 114. | ZW26X16000 | [1] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 115. | ZS18C16045 | [1] | SCREW,Hex, M16 x 45mm | KOBM16x2.0x45mm |
| 116. | 2416Z466 | [2] | STOP | KOBSTOPPER, RUBBER |
| 117. | 2416R223 | [1] | BRACKET | KOBBRACKET, LATCH |
| 118. | 24100J6436S118 | [1] | BRACKET, LATCH | |
| 119. | 24100J6436S119 | [7] | BOLT, SET | |
| 120. | 24100J6107S160 | [1] | NUT | KOB |
| 123. | 24100J6284S123 | [1] | BUSHING | |
| 124. | 24100J6436S124 | [1] | BUSHING | |
| 126. | 2416Z469D2 | [2] | SEAL, RUBBER RUBBER, SEAL | SEAL, RUBBER RUBBER, SEAL |
| 127. | 2416Z469D3 | [2] | SEAL, RUBBER RUBBER, SEAL | SEAL, RUBBER RUBBER, SEAL |
| 128. | 2427Z543 | [1] | TERMINAL CONNECTOR | KOBPLATE, CONNECTOR |
| 129. | 24100J6107S74 | [2] | SETSCREW SETSCREW | SETSCREW SETSCREW |
| 130. | 24100J6107S75 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 10mm | KOBSCREW Superseded by part number: ZS31C03010 |
| 131. | 24100J6107S76 | [2] | NUT NUT | NUT NUT |
| 132. | 24100J6436S132 | [1] | HARNESS | |
| 140. | 24100J6284S140 | [1] | GROMMET | |
| 143. | 2414R260 | [1] | GUARD | |
| 144. | 2414R258 | [1] | GUARD | GUARD |
| 145. | 2414R261 | [1] | GUARD GUARD | GUARD GUARD |
| 146. | 24100J6436S146 | [7] | BOLT | KOBBOLT, SET |
| 147. | 2414R254 | [1] | GUARD GUARD | GUARD GUARD |
| 148. | 2414R252 | [1] | GUARD GUARD | GUARD GUARD |
| 149. | 2414R256 | [1] | GUARD GUARD | GUARD GUARD |
| 150. | 2414R259 | [1] | GUARD GUARD | GUARD GUARD |
| 151. | 2414R251 | [1] | GUARD, Start Serial: YC-0101 | |
| 152. | 2414R250 | [1] | GUARD, Start Serial: YC-0101 | |
| 153. | 2414R253 | [1] | GUARD | |
| 154. | 2414R257 | [1] | GUARD GUARD | GUARD GUARD |
| 155. | 2414R255 | [1] | GUARD | |
| 156. | 2414R262 | [1] | GUARD GUARD, Start Serial: YC-0144 | GUARD GUARD, Start Serial: YC-0144 |
| 157. | 2414R263 | [1] | GUARD GUARD, Start Serial: YC-0144 | GUARD GUARD, Start Serial: YC-0144 |
