凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.110.09.AC) - INDUCTOR PLUMBING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
138 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN303189
|
[1] |
ELBOW,2" Flange x 1-1/4" Hose Barb, Poly
|
BN
2" Flange x 1-1/4" Hose Barb, Poly Superseded by part number: 405783A1
|
| 2. |
BN303196
|
[1] |
TEE,2" Flange x 2" Flange x 2" Flange, Poly
|
BN
2" Flange, Poly Superseded by part number: 405779A1
|
| 3. |
BN303199
|
[3] |
CLAMP,2" Flange
|
BN
2" Standard Flange Superseded by part number: 400502A1
|
| 4. |
BN303204
|
[3] |
GASKET,41.4mm ID x 55.63mm OD x 6.35mm Thk
|
BN
2" Flange, EPDM
|
| 5. |
BN304328
|
[1] |
VALVE
|
BN
Ball, 2" Flange, With Handle
|
| 6. |
BN320997
|
[1] |
BRACKET
|
BN
Decal Mount, Stainless Steel
|
| 7. |
BN306587
|
[1] |
DECAL
|
BN
Inductor Flow
|
| 8. |
BN310448
|
[4] |
HOSE CLAMP
|
BN
#28, Stainless Steel
|
| 9. |
BN312072
|
[1] |
HOSE,1.25" ID x 135.00"
|
BN
|
| 10. |
BN315700
|
[1] |
HOSE,1.50" ID x 360.00"
|
BN
EPDM
|
| 11. |
BN310467
|
[1] |
ELBOW
|
BN
1-1/2" NPT x 1-1/2" NPT, Poly, 45º Superseded by part number: 84325030
|
| 12. |
BN73725
|
[1] |
FITTING,1-1/2" Male NPT x 1-1/2" Hose Barb, Poly
|
BN
1-1/2" NPT x 1-1/2" Hose Barb, Poly Superseded by part number: 413083A1
|
| 13. |
515-23508
|
[1] |
CLAMP,2", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 87552805
|
| 14. |
BN50142
|
[1] |
WASHER,5/16", Stainless Steel
|
BN
|
| 15. |
BN50476
|
[1] |
BOLT,5/16"-18 x 0.75", Stainless
|
BN
|
| 16. |
BN55361
|
[1] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 17. |
86984085
|
[1] |
PLUG
|
SAS
2" Manifold
|
