神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (04-004) - AIR-LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
686 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X2443F1 | [1] | AIR LINES, UPP | |
| 1. | R38N0012 | [1] | RESERVOIR | KOB |
| 2. | 2446U156F1 | [1] | VALVE PRESSURE RELIE | KOBVALVE, REDUCTION |
| 2-21. | 2446U133S21 | [1] | AIR FILTER | KOB |
| 2-22. | 2446U133S22 | [1] | O-RING | KOB |
| 2-30. | 2446U156S30 | [1] | BOWL | KOB |
| 5. | MC802148 | [1] | GOVERNOR | |
| 6. | R38T0001D4 | [1] | VALVE PRESSURE RELIE | KOB |
| 7. | R38T0014 | [2] | VALVE | KOB |
| 9. | 2418P17548 | [1] | TUBE | KOB |
| 10. | ZX15K08090 | [1] | FLEXIBLE HOSE | KOB |
| 12. | ZX15K08020 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 16. | MH032863 | [1] | HOSE | |
| 18. | 2420Z809 | [1] | HOSE | KOB |
| 19. | 2436R339 | [2] | COCK, DRAIN | KOB |
| 20. | B20T0041 | [2] | U-BOLT | KOB |
| 21. | ZC15X01500 | [1] | CLIP | KOB |
| 23. | ZG81U04000 | [1] | CROSS | CROSS |
| 24. | ZG51U04000 | [1] | TEE | KOB |
| 25. | ZH31K04002 | [1] | ELBOW | KOB |
| 26. | ZG21E04000 | [6] | HYD CONNECTOR | KOB |
| 28. | ZH31K08004 | [2] | ELBOW | KOB |
| 30. | ZH21K08004 | [1] | HYD CONNECTOR | KOB |
| 31. | ZH21K04004 | [3] | HYD CONNECTOR | KOB |
| 32. | ZG21U04000 | [2] | SOCKET | KOBELBOW |
| 36. | R44T0198 | [1] | CONNECTOR | CONNECTOR |
| 37. | 2444T1169 | [2] | HYD CONNECTOR | KOB |
| 38. | 2444T1170 | [1] | HYD CONNECTOR | KOB |
| 39. | 2444Z1737D1 | [1] | CONNECTOR | CONNECTOR |
| 40. | 2444Z1293D7 | [1] | CONNECTOR Nipple, Hose -- 1/4\"PTx40mm Long | CONNECTOR Nipple, Hose -- 1/4"PTx40mm Long |
| 41. | ZC45X12011 | [3] | CLIP | CLIP |
| 42. | 2432Z290D2 | [5] | CLIP | KOBWire Ties -- 100mm Long Superseded by part number: YT50C01100P1 |
| 44. | ZS18C08014 | [3] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm |
| 45. | ZS18C06012 | [2] | SCREW,Hex, M6 x 12mm | KOBM06x1.0x12mm |
| 47. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 48. | ZW16X08000 | [7] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 49. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 50. | ZW26X08000 | [5] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 52. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 53. | MH035107 | [3] | GASKET, MITSUBISHI PART NO. | |
| 54. | MF660063 | [1] | GASKET | SUMMITSUBISHI PART NO. Superseded by part number: 132342A1 |
| 55. | MH035004 | [1] | GASKET, MITSUBISHI PART NO. | |
| 56. | 2479U497 | [1] | SENDER UNIT | KOB |
| 57. | ZG22B04002 | [1] | BUSHING | KOB |
| 58. | ZH31M08006 | [1] | ELBOW | KOB |
| 59. | ZG31B04000 | [1] | ELBOW | ELBOW |
| 60. | ZX15K04110 | [1] | TUBE, NYLON | TUBE, NYLON |
| 61. | ZX15K04120 | [1] | TUBE | KOB |
| 62. | ZS18C08035 | [2] | SCREW,Hex, M8 x 35mm | KOBM08x1.25x35mm |
