现代零件查询R80-7A ARM CYLINDER(#0108-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
971 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N1-51122
|
[1] |
CYLINDER ASSY
|
|
| 1. |
XKCD-02681
|
[1] |
TUBE ASSY
|
|
| 2. |
XKCD-01190
|
[1] |
BUSHING-PIN
|
|
| 3. |
XKCD-02682
|
[1] |
ROD ASSY
|
|
| 4. |
XKCD-01190
|
[1] |
BUSHING-PIN
|
|
| 5. |
XKCD-02272
|
[1] |
ROD COVER
|
|
| 6. |
XKCD-01004
|
[1] |
BUSHING-ROD
|
|
| 7. |
XKCD-01237
|
[1] |
RING-RETAINING
|
|
| K8. |
XKCD-02683
|
[1] |
BUFFER SEAL
|
|
| K9. |
XKCD-02684
|
[1] |
U-PACKING
|
|
| K10. |
XKCD-01101
|
[1] |
DUST WIPER
|
|
| 11. |
XKCD-01009
|
[1] |
RING-RETAINING
|
|
| K12. |
XKCD-00974
|
[1] |
O-RING
|
|
| K13. |
XKCD-01571
|
[1] |
BACK UP RING
|
|
| K14. |
XKCD-01198
|
[1] |
O-RING
|
|
| 15. |
XKCD-01572
|
[1] |
CUSHION RING
|
|
| 16. |
XKCD-01573
|
[1] |
PISTON
|
|
| K17. |
XKCD-01574
|
[1] |
PISTON SEAL
|
|
| K18. |
XKCD-01575
|
[2] |
WEAR RING
|
|
| K19. |
XKCD-01576
|
[2] |
DUST RING
|
|
| K20. |
XKCD-01245
|
[1] |
O-RING
|
|
| K21. |
XKCD-01838
|
[2] |
BACK UP RING
|
|
| 22. |
XKCD-02273
|
[1] |
NUT-PISTON
|
|
| 23. |
XKCD-01222
|
[1] |
SCREW-SET
|
|
| 24. |
XKCD-01577
|
[1] |
C/PLUNGER
|
|
| 25. |
XKCD-01261
|
[1] |
RING-STOP
|
|
| 26. |
XKCD-01578
|
[8] |
HEX SOCKET BOLT
|
|
| 27. |
XKCD-01579
|
[1] |
CHECK
|
|
| 28. |
XKCD-00984
|
[1] |
SPRING
|
|
| 29. |
XKCD-00453
|
[1] |
SUPPORT-SPRING
|
|
| 30. |
XKCD-00986
|
[1] |
PLUG-HEX SOCKET
|
|
| 31. |
XKCD-01582
|
[1] |
PIPE BAND ASSY
|
|
| 32. |
XKCD-01583
|
[1] |
PIPE BAND
|
|
| 33. |
XKCD-00533
|
[2] |
WASHER-SPRING
|
|
| 34. |
XKCD-01478
|
[2] |
HEX BOLT
|
|
| K35. |
XKCD-01479
|
[1] |
O-RING
|
|
| 36. |
XKCD-01584
|
[1] |
SPACER
|
|
| K37. |
XKCD-01479
|
[1] |
O-RING
|
|
| 38. |
XKCD-02274
|
[1] |
PIPE ASSY
|
|
| 39. |
XKCD-00989
|
[4] |
SPRING WASHER
|
|
| 40. |
XKCD-01481
|
[4] |
HEX SOCKET BOLT
|
|
| 41. |
XKCD-01587
|
[1] |
U-BOLT
|
|
| 42. |
XKCD-00989
|
[2] |
SPRING WASHER
|
|
| 43. |
XKCD-00990
|
[2] |
HEX NUT
|
|
| 44. |
XKCD-01213
|
[4] |
WIPER-PIN
|
|
| K45. |
XKCD-02685
|
[1] |
O-RING
|
|
| K. |
XKCD-02275
|
[1] |
SEAL KIT
|
|
