凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.110.14.CD) - BOOM PLUMBING, 60', 3" TUBES, RH, OUTER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
810 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN25237
|
[5] |
NOZZLE
|
BN
1 Way, 3/4" Pipe Superseded by part number: 51405667
|
| 2. |
BN300292
|
[1] |
BAR
|
BN
Spraybar, Mid, RH
|
| 3. |
BN300293
|
[1] |
BAR
|
BN
Spray, Outer, RH
|
| 4. |
BN34458
|
[1] |
U-BOLT
|
BN
1/4" x 1.12 ID CR RD
|
| 5. |
BN50212
|
[4] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 6. |
BN55359
|
[16] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 7. |
BN55379
|
[8] |
BOLT,1/4"-20 X 2-1/4", Stainless Steel
|
BN
|
| 8. |
BN65324
|
[4] |
CLAMP
|
BN
1" OD, Poly
|
| 9. |
BN66858
|
[1] |
HOSE
|
BN
1" EPDM X 31.00"
|
| 10. |
BN67983
|
[1] |
SUPPORT
|
BN
Outer Spraybar
|
| 11. |
BN68011
|
[1] |
U-BOLT
|
CUR
BOLT "U" 1/4-20 SS, 1" pipe
|
| 12. |
BN68981
|
[4] |
BRACKET
|
BN
Spraybar
|
| 13. |
BN73553
|
[1] |
PLUG
|
BN
3/4" NPT, Poly
|
| 14. |
BN74619
|
[5] |
CAP
|
BN
With Gasket, Black Superseded by part number: 51402278
|
| 15. |
BN310447
|
[3] |
HOSE CLAMP
|
BN
#20, Stainless Steel
|
| 16. |
BN311249
|
[4] |
PLATE
|
BN
Top, Single, Size 3
|
