神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (06-001) - INSTALL, LOW Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
444 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6443F1 | [1] | INSTALL, LOW | |
| 1. | 2422J1785 | [1] | FRAME, LOW | |
| 2. | 24100N3099F4 | [2] | IDLER WHEEL | KOBSEE FIGURE 06-002 Superseded by part number: LC52DU0001F1 |
| 3. | 24100N3856F1 | [18] | TRACK ROLLER | KOBSEE FIGURE 06-003 Superseded by part number: 24100N3856F3 |
| 4. | 24100N3841F2 | [4] | TRACK ROLLER | KOBSEE FIGURE 06-004 Superseded by part number: 24100N3841F4 |
| 5. | 24100J5256F3 | [2] | TRACK LINK | KOBSEE FIGURE 06-005 |
| 6. | 2441U577F2 | [2] | MOTOR ASSY | MOTOR ASSY |
| 6-2. | 2436U1027F1 | [1] | BRAKE VALVE | KOB |
| 6-3. | 2453U275F1 | [1] | HYDRAULIC MOTOR | KOBSEE FIGURE 06-006 |
| 6-4. | 2441U563F4 | [1] | HYDRAULIC MOTOR | KOB |
| 7. | 2404N217D2 | [2] | DRIVING SPROCKET | KOB |
| 8. | 24100N3854F1 | [1] | SLEWING RING | KOBBEARING ASSY SEE FIGURE 06-007 |
| 9. | 2436U912F2 | [1] | JOINT, SWIVEL | JOINT, SWIVEL |
| 10. | ZS18C16120 | [1] | CAPSCREW,Hex, M16 x 120mm | KOBSCREW M16x2.0x120mm |
| 11. | 2420Z1622 | [36] | CAPSCREW | CAPSCREW |
| 12. | ZS18C20130 | [4] | CAPSCREW,Hex, M20 x 130mm | KOBSCREW M20x2.50x130mm |
| 13. | 2420N458D20065 | [44] | SCREW | KOB |
| 14. | ZS18C10014 | [4] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm |
| 15. | ZN18C16013 | [1] | NUT | KOBM16x2.0mm |
| 16. | ZN18C20016 | [4] | NUT | KOBM20x2.5mm |
| 17. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 18. | 2414P4770 | [2] | GUIDE | KOB Superseded by part number: 2414P4770K |
| 19. | 2420Z1671 | [8] | CAPSCREW | CAPSCREW |
| 20. | ZW16H20000 | [40] | WASHER | KOBID 21 x OD 40 x Th 4.5mm |
| 21. | ZW16H24000 | [8] | WASHER | KOBID 25 x OD 48 x Th 6.0mm |
| 22. | 2414T1597 | [1] | COVER | KOB |
| 23. | 2418T8720 | [1] | PACKING | KOB |
| 24. | 2414N1995D1 | [1] | COVER | KOB |
| 25. | 2414N1995D2 | [1] | COVER | KOB |
| 26. | 2414N1993D1 | [1] | COVER | |
| 27. | 2414N1993D2 | [1] | COVER | |
| 28. | 2420Z1623 | [72] | SCREW | KOB Superseded by part number: 2420Z1309 |
| 29. | 2420N458D12030 | [3] | SCREW,Hex Socket Head, M12 x 30mm | KOBCAPSCREW Superseded by part number: ZS28C12030 |
| 30. | ZW16H22000 | [72] | WASHER | KOBID 23 x OD 44 x Th 6.0mm |
| 31. | ZW26K12000 | [3] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 32. | ZS18C16025 | [10] | SCREW,Hex, M16 x 25mm | KOBM16x2.0x25mm |
| 33. | ZW26X16000 | [18] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 34. | ZS18C20050 | [44] | SCREW,Hex, M20 x 50mm | KOBM20x2.50x50mm |
| 35. | ZS18C16030 | [8] | SCREW,Hex, M16 x 30mm | KOBM16x2.0x30mm |
| 36. | ZW16X16000 | [18] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 37. | 2420Z1214 | [8] | SET OF SCREWS | KOB |
