凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.110.21.AA) - HAND RINSE PLUMBING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
796 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN309282
|
[1] |
TANK
|
BN
Rinse, 75 Gallon, Gray
|
| 2. |
87502088
|
[1] |
FITTING
|
SAS
1" Manifold X 1" Male
|
| 3. |
408350A1
|
[1] |
MANIFOLD GASKET
|
FLX
1” Flange, EPDM
|
| 4. |
406041A1
|
[1] |
CLAMP,58.51mm
|
FLX
1" Flange
|
| 5. |
405785A1
|
[1] |
ELBOW
|
FLX
1" Flange x 3/4" Hose Barb, Poly
|
| 6. |
BN310446
|
[2] |
HOSE CLAMP
|
BN
#12, Stainless Steel
|
| 7. |
BN27905
|
[1] |
HOSE,19.05mm ID x 304.8mm L
|
BN
3/4" ID, Bulk, Cut to Length of 190"
|
