凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.120.02.AB) - FOAM MARKER DROP, LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
724 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84163486
|
[1] |
VENTURI
|
BN
Assembly Superseded by part number: 87269827, 86986807, BN307938, BN324008, BN2399403, BN2399411
|
| 2. |
87266747
|
[2] |
U-BOLT
|
CUR
1/4"-20 x 2.5 ID x 3"
|
| 3. |
87485006
|
[1] |
CLAMP,0.5" - 0.91"
|
BRR
#8, Stainless Steel
|
| 4. |
86986173
|
[1] |
HOSE,0.50" ID x 200.00"
|
BN
|
| 5. |
86986175
|
[1] |
TUBE,0.375" DIA x 200" L
|
BN
SYNFLEX, 3/8" X 200"
|
| 6. |
BN310447
|
[2] |
HOSE CLAMP
|
BN
#20, Stainless Steel
|
| 7. |
BN50138
|
[8] |
WASHER,1/4", SS
|
BN
|
| 8. |
BN55359
|
[12] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 9. |
BN67054
|
[4] |
CLAMP
|
BN
1.315" OD
|
| 10. |
BN309483
|
[2] |
PLATE
|
BN
Clamp Top, Single Clamp
|
| 11. |
BN67050
|
[4] |
BOLT,1/4"-20 X 3.00", Stainless Steel
|
BN
|
| 12. |
86986166
|
[1] |
TUBE,69.10" L
|
TYR
Foam Drop
|
| 13. |
87266751
|
[1] |
HOSE
|
BN
1-1/4" X 262", TYPE K
|
| 14. |
BN310939
|
[1] |
ELBOW
|
BN
2" Hose Barb x 1-1/4" Hose Barb, 90 DEG, Poly
|
| 15. |
BN310449
|
[2] |
CLAMP,50mm - 65mm
|
BN
#32, Stainless Steel
|
| 16. |
87268528
|
[1] |
HOSE,2.00" ID x 26.00"
|
BN
Foam Drop
|
| 17. |
BN2403252
|
[1] |
BELL
|
BN
Foam Marker
|
| 18. |
515-23412
|
[3] |
CLAMP,1 5/8", Insul, 3/8" Bolt
|
CAS
|
| 19. |
BN50212
|
[1] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 20. |
515-23302
|
[2] |
CLAMP,1 3/16", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 87035382
|
| 21. |
BN2399412
|
[1] |
ADAPTER
|
BN
3/8" MPT x 3/8" OD Tube, Push Lock Fitting
|
| 22. |
BN307636
|
[1] |
CHAMBER
|
BN
Foam Mixing
|
| 23. |
BN305269
|
[1] |
COUPLING
|
BN
1.25 FP
|
| 24. |
BN73660
|
[1] |
FITTING,1-1/4" Male NPT x 1-1/4" Hose Barb, Poly
|
BN
1-1/4" NPT X 1-1/4" Hose Barb, Poly Superseded by part number: 87743696
|
| 25. |
84422568
|
[1] |
TUBE,3/8" X 50' BULK, SAE J844, BLACK
|
PA
Air, Synflex 3/8" Black, Bulk, Bulk, Cut to Length of 15"
|
