凯斯零件查询(FLEX-AIR) - APPLICATOR (1995-1997) (2/95-2/97) (03-002) - TRIPLE BIN GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
632 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN10054
|
[8] |
COLLAR
|
BN
1 1/4" od x 3/4" id HRST
|
| 2. |
BN15711
|
[1] |
Panel - Conveyor, Outside, W/CO-AP
|
|
| 3. |
BN15712
|
[1] |
Panel - Conveyor, Inside, W/CO-AP
|
|
| 4. |
BN15717
|
[2] |
PIN
|
BN
Snap, 1/4" x 1 3/4"
|
| 5. |
BN15900
|
[2] |
PIN
|
BN
CO-AP Bin Pivot
|
| 6. |
BN20260
|
[4] |
CABLE
|
BN
1/4"
|
| 7. |
BN20307
|
[4] |
Cable 1/4 IN
|
|
| 8. |
BN21398A
|
[4] |
COUPLING
|
BN
Machined
|
| 9. |
BN21652
|
[8] |
PIN
|
BN
3/8 x 2
|
| 10. |
BN22944
|
[2] |
ADAPTER
|
BN
Male 4" Nyglass
|
| 11. |
BN22945
|
[2] |
CAP
|
BN
4" DC Nyglass Superseded by part number: BN2393389
|
| 12. |
BN23002
|
[2] |
SENSOR
|
BN
Low Hopper - DJ100
|
| 13. |
BN23298
|
[2] |
COVER
|
BN
14 GA 304 1.5 X 2.0
|
| 14. |
BN23309
|
[2] |
PIPE UNION NUT
|
BN
4" Pipe Thread
|
| 15. |
BN23310
|
[2] |
GASKET
|
BN
4"
|
| 16. |
BN35411
|
[4] |
HANDLE
|
TYR
Gate, Conveyor
|
| 17. |
BN35576
|
[2] |
COVER
|
BN
Supply Bin Access
|
| 18. |
BN35705
|
[4] |
BEARING HOUSING
|
BN
Valmar, Housing, LH
|
| 19. |
BN35706
|
[4] |
BEARING HOUSING
|
BN
Valmar - Housing, RH
|
| 20. |
BN35707
|
[8] |
BEARING CAP
|
BN
Valmar - Latch
|
| 21. |
BN35740
|
[2] |
SCREEN
|
TYR
CO-AP Bin
|
| 22. |
BN35758
|
[1] |
COVER
|
BN
CO-AP Bin, RH
|
| 23. |
BN35761
|
[4] |
HINGE
|
BN
CO-AP Bin Cover
|
| 24. |
BN35764
|
[1] |
COVER
|
BN
CO-AP Bin, LH
|
| 25. |
BN35772
|
[4] |
SIDE PLATE
|
BN
Divider, CO-AP Bin
|
| 26. |
BN35773
|
[2] |
DIVIDER
|
BN
Top, CO-AP Bin
|
| 27. |
BN35774
|
[2] |
SHEET
|
BN
Supplemental - Bolt - On W/M
|
| 28. |
BN35779
|
[2] |
COVER
|
BN
Divider, CO-AP Bin
|
| 29. |
BN35784
|
[2] |
PIN
|
BN
with hole, CO-AP Bin
|
| 30. |
BN35785
|
[4] |
SLIDE
|
BN
Vertical, CO-AP Gate
|
| 31. |
BN35786
|
[8] |
LINK
|
BN
CO-AP Bin Gate
|
| 32. |
BN35787
|
[2] |
GATE ASSY
|
BN
CO-AP Bin
|
| 33. |
BN35788
|
[4] |
SEAL
|
BN
CO-AP Gates
|
| 34. |
BN35789
|
[2] |
SEAL
|
BN
CO-AP Gates
|
| 35. |
BN35790
|
[2] |
COVER
|
BN
CO-AP Bin Gate
|
| 36. |
BN35791
|
[2] |
SLIDE
|
BN
Horizontal, CO-AP Gate
|
| 37. |
BN35793
|
[2] |
GATE ASSY
|
BN
Supply Bin
|
| 38. |
BN35796
|
[4] |
SHAFT
|
BN
Supply Gate
|
| 39. |
BN35799
|
[8] |
LINKAGE
|
BN
Supply Gate
|
| 40. |
BN35800
|
[8] |
BUSHING
|
BN
Shaft, Supply Gate
|
| 41. |
BN35801
|
[8] |
SEAL
|
BN
Shaft, Supply Gate
|
| 42. |
BN35857
|
[2] |
MOUNTING PLATE
|
BN
CO-AP Bin, Center
|
| 43. |
BN65711
|
[4] |
CAP
|
BN
Rectifier, 1.25 X .162 X 4.00
|
| 44. |
BN23023
|
[4] |
PIN
|
BN
Cover Tie Down
|
| 45. |
BN35862
|
[6] |
MOUNTING PLATE
|
BN
CO-AP Bin, Frame
|
| 46. |
BN35864
|
[1] |
MOUNTING PLATE
|
BN
CO-AP Bin - RH
|
| 47. |
BN35865
|
[1] |
CO-AP Bin - LH
|
|
| 48. |
87265978
|
[6] |
WINDOW
|
BN
Co-Ap Bin
|
| 49. |
BN35938
|
[2] |
ARM
|
BN
Torque - CO-AP, RH
|
| 50. |
BN35939
|
[2] |
ARM
|
BN
Torque - CO-AP, LH
|
| 51. |
BN35940
|
[2] |
PIN
|
BN
Torque Arm
|
| 52. |
BN35961
|
[1] |
SUPPORT
|
TYR
Mount, CO-AP Bin, Center
|
| 53. |
BN65327
|
[4] |
BRACKET
|
BN
CO-AP Side Cover
|
| 54. |
BN65330
|
[1] |
BRACKET
|
BN
LH, CO-AP Side Cover
|
| 55. |
BN65331
|
[1] |
BRACKET
|
BN
RH, CO-AP Side Cover
|
| 56. |
BN65334
|
[2] |
COVER
|
BN
Conveyor, W/CO-AP Bin
|
| 57. |
BN65349
|
[1] |
LADDER
|
BN
CO-AP Bin
|
| 58. |
BN65366
|
[1] |
HANDRAIL
|
BN
CO-AP Bin
|
| 59. |
BN65378
|
[4] |
SPACER
|
BN
CO-AP Rail
|
| 60. |
BN65379
|
[2] |
MOUNTING PLATE
|
BN
CO-AP Handrail
|
| 61. |
BN65384
|
[1] |
MOUNTING PLATE
|
BN
Walkway-Plank, CO-AP Bin Wheel
|
| 62. |
BN65423
|
[2] |
COVER
|
BN
CO-AP Bin
|
| 63. |
BN65430
|
[4] |
Pin, 3/8 X 1.38
|
|
| 64. |
BN300185
|
[2] |
1/4 X 42.00, SS
|
|
| 65. |
BN71007
|
[18] |
CLIP,3/16" Hairpin
|
BN
3/16" #8
|
| 66. |
BN65718
|
[4] |
HYDRAULIC MOTOR
|
BN
Hydro, Ross MG12
|
| 67. |
BN95852
|
[4] |
SENSOR
|
BN
Application Rate D-J#CCS1
|
| 68. |
BN22884
|
[4] |
KIT
|
BN
Adaptor
|
| 69. |
BN66758
|
[1] |
COVER
|
BN
Wind (RH, CO-AP)
|
| 70. |
BN66759
|
[1] |
COVER
|
TYR
Wind (LH CO-AP)
|
| 71. |
87265980
|
[2] |
WINDOW
|
BN
Hopper 12" x 8"
|
| 72. |
BN67438
|
[2] |
SEAL
|
BN
Weather, Wind Cover
|
