现代零件查询R800-7A FS PRE HEATING GROUP(#0002-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
267 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
11N8-90620
|
[1] |
PRE HEATER KIT
|
|
| 1-1. |
11N8-90610
|
[1] |
PRE HEATER ASSY
|
|
| 1-2. |
11N8-90630
|
[1] |
TIMER-CONTROL
|
|
| N1-3. |
11N8-90640
|
[1] |
PUMP
|
|
| 1-4. |
11N8-90650
|
[1] |
SILENCER ASSY
|
|
| 1-5. |
11N8-90660
|
[1] |
BRACKET
|
|
| 1-6. |
11N8-90670
|
[1] |
FRONT CASE-TIMER
|
|
| 1-7. |
11N8-90680
|
[1] |
HOSE
|
|
| 1-8. |
11N8-90690
|
[3] |
CLAMP-EXHAUST PIPE
|
|
| 1-9. |
11N8-90700
|
[1] |
HOSE-INTAKE
|
|
| 1-10. |
11N8-90710
|
[1] |
HOSE
|
|
| 1-11. |
11N8-90720
|
[2] |
CONNECTOR-HOSE
|
|
| N1-12. |
11N8-90730
|
[1] |
DAMPER ASSY
|
|
| 1-13. |
11N8-90740
|
[1] |
HOSE
|
|
| 1-14. |
11N8-90750
|
[4] |
HOSE
|
|
| 1-15. |
11N8-90770
|
[1] |
HARNESS PRE HEAT
|
|
| 1-16. |
@
|
[1] |
CLAMP
|
|
| 1-17. |
@
|
[1] |
CLAMP
|
|
| 1-18. |
@
|
[2] |
CLAMP
|
|
| 1-19. |
@
|
[4] |
CLAMP
|
|
| 1-20. |
@
|
[4] |
CLAMP
|
|
| 1-21. |
@
|
[8] |
CLAMP
|
|
| 2. |
11ND-94210
|
[1] |
BRACKET WA
|
|
| 3. |
11ND-94230
|
[1] |
BRACKET
|
|
| 4. |
11E6-92070
|
[1] |
HOSE-HEATER
|
|
| 5. |
11EK-92070
|
[1] |
HOSE-HEATER
|
|
| 6. |
11N8-94180
|
[1] |
TEE-FUEL
|
|
| 7. |
11ND-94220
|
[1] |
CONNECTOR-HOSE
|
|
| 8. |
S411-080006
|
[1] |
WASHER-SPRING
|
|
| 9. |
S205-08000B
|
[1] |
NUT-HEX
|
|
| 10. |
S037-081826
|
[3] |
BOLT W/WASHER-HEX
|
|
| 11. |
S037-062026
|
[8] |
BOLT-W/WASHER-HEX
|
|
| 12. |
S131-041016
|
[2] |
SCREW W/WASHER CR RH
|
|
| 13. |
S151-060166
|
[2] |
SCREW-TAPPING
|
|
| 14. |
S037-101526
|
[2] |
BOLT-W/WASHER
|
|
| 15. |
S520-020000
|
[2] |
CLAMP-HOSE
|
|
| 16. |
31L7-10220
|
[3] |
CLAMP-TUBE
|
|
| 17. |
31L7-10220
|
[3] |
CLAMP-TUBE
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
