神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (11-010) - VALVE ASSY, PORT RELIEF 2436R837 F1, F2, F3, F4, F5 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
182 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R837F1 | [1] | VALVE ASSY PORT RELIEF, CONSISTS OF THE FOLLOWING PARTS | |
| . . | 2436R837F2 | [1] | VALVE PRESSURE RELIE | KOBASSY, PORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 2436R837F3 | [1] | VALVE PRESSURE RELIE | KOBASSY, PORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 2436R837F4 | [1] | VALVE PRESSURE RELIE | KOBASSY, PORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 2436R837F5 | [1] | VALVE PRESSURE RELIE | KOBASSY, PORT, CONSISTS OF THE FOLLOWING PARTS |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 161. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 162. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 163. | 2436R837S163 | [1] | O-RING | KOB |
| 164. | ZD85P00700 | [1] | BACK-UP RING | KOBID 07 x OD 10 x Th 1.25mm |
| 201. | 2436R683S201 | [1] | PLUG | KOB |
| 261. | ZD12P02200 | [1] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 511. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER |
| 521. | 2436R819S521 | [1] | SPRING | KOB |
| 522. | 2436R683S522 | [1] | SPRING | KOB |
| 541. | 2436R831S541 | [1] | SEAT | KOB |
| 611. | 2436R682S401 | [1] | POPPET | KOB |
| 612. | 2436R682S521 | [1] | SEAT | KOB |
| 613. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT SPRING |
| 621. | 2436R683S1 | [1] | SPRING | KOB |
| 641. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT |
| 651. | 2436R683S651 | [1] | SET SCREW | KOB |
| 663. | ZD12P00600 | [1] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| 671. | ZN11C12007 | [1] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12007 |
