卡特零件查询（730C2） 364-5177: GUARD GP-PLATFORM
广数供应链运营团队, 15 02月, 2025，浏览：
1001 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 415-3887 | [1] | HANDRAIL AS(RH) | |
| 2. | 415-3889 | [1] | HANDRAIL AS(LH) | |
| 3. | 417-3643 | [1] | PLATE | |
| 4. | 425-5801 | [1] | HANDRAIL AS | |
| | 7T-1099 | [7] | LINK | |
| | 9X-2032M | [2] | NUT-WELD(M4X0.7-THD) | |
| 5. | 425-5777 | [1] | HANDRAIL AS(LH) | |
| 6. | 425-5802 | [1] | HANDRAIL AS | |
| | 7T-1099 | [7] | LINK | |
| | 9X-2032M | [2] | NUT-WELD(M4X0.7-THD) | |
| 7. | 425-5779 | [1] | HANDRAIL AS(RH) | |
| 8. | 428-7340 | [1] | PLUG | |
| 9. | 7X-2555M | [4] | BOLT(M16X2X80-MM) | |
| 10. | 8T-4139M | [12] | BOLT(M12X1.75X30-MM) | |
| 11. | 8T-4183M | [4] | BOLT(M12X1.75X40-MM) | |
| 12. | 8T-4223 | [16] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 13. | 9X-2040M | [2] | SCREW-TRUSS HEAD(M10X1.5X25-MM) | |
| 14. | 9X-8257 | [4] | WASHER(17.5X30X3.5-MM THK) | |
| | M | | METRIC PART |
