神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (11-031) - MOTOR ASSY, (PROPELLING) 2441U792 F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
807 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U792F1 | [1] | HYDRAULIC MOTOR | KOBPROPELLING, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2441U792F3 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER ASSY |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER |
| 6. | NSS | [2] | NOT SOLD SEPARAT | CONVALVE CHECK |
| 7. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING |
| 8. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 9. | ZD12P02100 | [2] | O-RING,2.4mm Thk x 20.8mm ID, 90 Duro | KOBO-Ring -- ID 20.80 ± 0.23 x OD 25mm |
| 10. | 2436U1027S203 | [2] | SEAT/SLOT | KOB |
| 11. | 2441U792S11 | [2] | SPRING | KOB |
| 12. | 2441U792S12 | [2] | SPRING SEAT | KOB |
| 13. | 2441U792S13 | [2] | CAP | KOB |
| 14. | NSS | [2] | NOT SOLD SEPARAT | CONCAP |
| 15. | ZD12G04500 | [2] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 16. | ZS23C12040 | [8] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 17. | 2436U281S37 | [2] | BALL | KOB |
| 18. | 2441U792S18 | [2] | SPRING | SM |
| 19. | 2441U792S19 | [2] | PLUG | SM |
| 20. | ZD12P00800 | [2] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 21. | 2436R834F1 | [2] | VALVE | KOB |
| 22. | NSS | [8] | NOT SOLD SEPARAT | CONPLUG |
| 23. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| 25. | ZD12P01200 | [1] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 26. | 2441U792S26 | [1] | HYDRAULIC VALVE | KOB |
| 27. | 2441U598S21 | [1] | PLUG | KOB |
| 28. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 29. | 2441U792S29 | [1] | PLUG | KOB |
| 31. | 2441U792S31 | [1] | SPRING | SPRING |
| 32. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 33. | NSS | [4] | NOT SOLD SEPARAT | CONORIFICE |
| 34. | NSS | [2] | NOT SOLD SEPARAT | CONORIFICE |
| 35. | 2441U792S35 | [2] | PLUG | KOBPLUG |
| 36. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 37. | NSS | [2] | NOT SOLD SEPARAT | CONSETSCREW |
| 103. | 2441U792S103 | [1] | SHAFT | KOB |
| 104. | NSS | [1] | NOT SOLD SEPARAT | CONBLOCK CYLINDER |
| 105. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE VALVE |
| 106. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON ASSY |
| 107. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE RETAINER |
| 108. | NSS | [1] | NOT SOLD SEPARAT | CONHOLDER RETAINER |
| 109. | 2441U792S109 | [1] | PLATE | KOBPLATE |
| 110. | 2441U792S110 | [2] | BALL | KOB |
| 111. | 2441U792S111 | [2] | PISTON | KOB |
| 112. | 2441U792S112 | [1] | ROLLER BEARING | KOB |
| 113. | 2441U792S113 | [1] | BEARING | KOB |
| 114. | ZR26X06200 | [1] | SNAP RING | KOB |
| 115. | 2441U792S115 | [1] | SPRING SEAT | KOB |
| 116. | 2441U792S116 | [1] | SPRING | KOB |
| 117. | 2441U792S117 | [1] | COLLAR | KOB |
| 118. | 2441U563S117 | [1] | PIN | KOB |
| 119. | 2441U792S119 | [3] | PIN | KOB |
| 120. | ZS23C12050 | [14] | SET SCREW,Hex Socket Head, M12 x 50mm | KOBM12x1.75x50mm |
| 121. | 2441U792S121 | [1] | OIL SEAL | KOB |
| 122. | 2441U792S122 | [1] | O-RING | KOB |
| 123. | 2441U792S123 | [1] | O-RING | KOB |
| 124. | 2441U792S124 | [1] | O-RING | KOB |
| 125. | 2441U792S125 | [1] | PISTON | KOB |
| 126. | 2441U792S126 | [1] | COLLAR CLAMP | KOB |
| 128. | 2441U792S128 | [2] | DISK DRILL | KOB |
| 129. | 2441U792S129 | [2] | PIN | KOB |
| 130. | 2441U792S130 | [8] | SPRING | KOB |
| 131. | 2441U563S142 | [1] | O-RING | KOB |
| 132. | 2441U792S132 | [1] | O-RING | KOB |
| 133. | 2441U792S133 | [1] | BACK-UP RING | KOB |
| 134. | 2441U792S134 | [1] | BACK-UP RING | KOB |
| 135. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 136. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 137. | NSS | [4] | NOT SOLD SEPARAT | CONPLUG |
| 138. | 2441U792S138 | [4] | SPRING | KOB |
| 139. | NSS | [1] | NOT SOLD SEPARAT | CONORIFICE |
| 140. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 141. | 2441U792S141 | [2] | PLUG | KOB |
| 142. | 2441U792S142 | [2] | SPRING | KOB |
| 143. | 2441U792S143 | [3] | SHIM | KOB |
| 144. | 2441U792S144 | [3] | SHIM | KOB |
| 145. | 2441U792S145 | [3] | SHIM | KOB |
| 146. | NSS | [2] | NOT SOLD SEPARAT | CONFILTER |
| 147. | NSS | [2] | NOT SOLD SEPARAT | CONSLEEVE |
| 301. | ZS23C12080 | [3] | SCREW,Hex Socket Head, M12 x 80mm | KOBM12x1.75x80mm |
| 400. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 500. | NSS | [2] | NOT SOLD SEPARAT | CONSCREW DRIVE |
| . . | 2441U792R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF 104-106 Superseded by part number: 2441U792R600 |
| . . | 2441U792R200 | [1] | REPAIR KIT | KOBCONSISTS OF REF 107 AND 108 |
| . . | 2441U792R300 | [1] | REPAIR KIT | KOBCONSISTS OF REF 143-145 |
| . . | 2441U792R400 | [1] | REPAIR KIT | KOBCONSISTS OF REF 131-135 |
