| . . | 24100J10874F4 | [1] | REMOTE-CONTROL ASSY | |
| 1. | R18P0168D68 | [1] | HOSE | KOBRUBBER HOSE Superseded by part number: R18P0168D63 |
| 2. | ZC15X03300 | [4] | CLIP | KOB |
| 3. | 2418P10004 | [1] | TUBE | KOB |
| 4. | ZA23F22012 | [1] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 5. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 7. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 8. | 2444Z3163 | [1] | HYD CONNECTOR | KOBCONNECTOR Superseded by part number: 2444Z3178D2 |
| 10. | 2420R537D050 | [1] | HOSE,9.53mm ID x 500mm L | KOB |
| 12. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 13. | 2444R963D7 | [1] | HOSE,6.35mm ID x 500mm L | KOB |
| 14. | 2416P13806 | [1] | BRACKET | KOB |
| 15. | ZS13C10020 | [2] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 16. | ZS13C08020 | [4] | SCREW | KOBM08x1.25x20mm Superseded by part number: ZS18C08020 |
| 17. | ZW22X08000 | [6] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 18. | 2445R373F1 | [1] | ACCUMULATOR | KOB |
| 19. | 2444Z3134 | [1] | TEE | KOB1/4" PF x 40mm Long |
| 20. | 2425Z519 | [2] | BALL | KOB |
| 21. | ZH32X06008 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 22. | 2444T2528 | [1] | HYD CONNECTOR | KOB |
| 23. | 2446R151F1 | [1] | ELEMENT | KOBFILTER, LINE Superseded by part number: 2446R183F1 |
| 23-1. | 2446R151S1 | [1] | HEAD | KOB |
| 23-2. | R36P0019 | [1] | HYDRAULIC OIL FILTER | KOBELEMENT |
| 23-3. | 45Z91D84 | [1] | O-RING | KOBID 56.74 ± 0.25 OD 63.80mm |
| 23-4. | 2446R151S4 | [1] | RING | KOB |
| 23-5. | 2446R151S5 | [1] | CASE | KOB |
| 24. | 2444Z2489 | [1] | HYD CONNECTOR | KOB |
| 25. | 2436R680F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 26. | ZS13C08055 | [1] | SCREW | KOBM08x1.25x55mm Superseded by part number: ZS18C08055 |
| 27. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 28. | 2444Z2892 | [1] | TEE | KOB(Incls. O-Ring ZD12P01400) |
| 29. | 2416T22061 | [1] | BRACKET | BRACKET |
| 30. | ZS13C06060 | [1] | SCREW | KOBBOLT M06x1.0x60mm Superseded by part number: ZS18C06060 |
| 31. | ZS13C08016 | [1] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 32. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 33. | ZW22X06000 | [1] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 34. | 2444Z2335 | [1] | CONNECTION | KOB |
| 35. | ZH31M08004 | [1] | ELBOW | KOB |
| 36. | 2444Z3179D6 | [2] | HYD CONNECTOR | KOB |
| 37. | 2444Z3279 | [1] | 90 ELBOW | KOB90° -- 3/8"PF-3/8"PFx32mm Long (Incls. O-Ring ZD12P01400) |
| 38. | 2444Z3148 | [1] | HYD CONNECTOR | KOB |
| 39. | 2444Z2890 | [1] | HYD CONNECTOR | KOB |
| 40. | ZH32X04000 | [6] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), Serial Range: YC0301--YC0572 |
| . . | ZH32X04000 | [5] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), Start Serial: YC0573- |
| 41. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 45. | 2420R349D075 | [1] | HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: 2444R3019D3 |
| 46. | 2420R349D180 | [2] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 47. | ZH52X04000 | [4] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004), Serial Range: YC0301--YC0572 |
| . . | ZH52X04000 | [3] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004), Start Serial: YC0573- |
| 48. | 2444T2505 | [1] | HYD CONNECTOR | KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400) |
| 51. | 2444T2529 | [1] | TEE | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 52. | 2444R963D19 | [1] | FLEXIBLE HOSE | HIT1500 mm long (59-3/64 in) |
| 53. | 2444Z2448F1 | [2] | HYD CONNECTOR | KOB |
| 54. | 2444R963D14 | [1] | FLEXIBLE HOSE | KOB2200mm Long (86-39/64 in) |
| 55. | ZX15K08110 | [1] | KIT | KOB |
| 56. | ZH51K08000 | [1] | TEE | KOB |
| 57. | ZX15K08037 | [1] | TUBE, N2 | TUBE, N2 |
| 58. | 2444Z2546F1 | [1] | HYD CONNECTOR | KOB |
| 59. | 2436U1282D2108 | [1] | VALVE PRESSURE RELIE | KOB |
| 60. | 2444Z2535 | [1] | HYD CONNECTOR | KOB |
| 61. | ZX15K08090 | [1] | FLEXIBLE HOSE | KOB |
| 62. | ZH21M08006 | [5] | HYD CONNECTOR | KOBCONNECTOR |
| 64. | 2444Z2345 | [1] | 90 ELBOW | KOB90° -- (Incls. O-Rings ZD12P01400 & ZD12P01800) |
| 65. | ZX15K08005 | [1] | TUBE | KOB |
| 66. | 2436U1171D36 | [1] | CHECK VALVE | KOB |
| 67. | 2436U1171D31 | [1] | CHECK VALVE | KOB |
| 69. | ZX15K08300 | [1] | FLEXIBLE HOSE | KOB |
| 70. | 2420R537D180 | [1] | HOSE,9.60mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 71. | 2444T3298 | [1] | TEE | KOB3/8" PF - 1/4" PF (Incls. O-Ring ZD12P01100) |
| 73. | 2444Z2526 | [1] | TEE | KOB |
| 74. | 2444R974D6 | [1] | HOSE | KOB |
| 75. | 2420R349D050 | [2] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 76. | ZH42X04000 | [2] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004), Serial Range: YC0301--YC0572 |
| . . | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004), Start Serial: YC0573- |
| 77. | 2420R349D065 | [1] | HOSE,650.00 mm | KOB650mm Long (25-1/2 in) Superseded by part number: HX21E04065DX |
| 80. | 2420R349D110 | [1] | HOSE,1100.00 mm | KOB1100mm Long (43-19/64 in) Superseded by part number: HX21E04110DX |
| 81. | 2420R349D070 | [1] | HOSE,700.00 mm | KOB700mm Long (27-9/16 in) |
| 82. | 2444Z2448F3 | [1] | HYD CONNECTOR | KOB, Serial Range: YC0301--YC0680 |
| 85. | 2444T2533 | [1] | TEE | KOB(Incls. O-Ring ZD12P01400) Superseded by part number: 87635046 |
| 86. | 2444Z2447F3 | [2] | ELBOW UNION | KOBUnion Elbow |
| 88. | 2444T2524 | [1] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 89. | 2436U1240F1 | [1] | SOLENOID VALVE | KOB |
| 90. | ZH22X04000 | [7] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), Serial Range: YC0301--YC0460 |
| . . | ZH22X04000 | [5] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), Start Serial: YC0461- |
| 91. | 2444T2639F1 | [2] | HYD CONNECTOR | KOBCONNECTOR ASSY., Serial Range: YC0461--YC0680 Superseded by part number: 2444Z2448F3 |
| . . | 2444T2639F1 | [3] | HYD CONNECTOR | KOBCONNECTOR ASSY., Serial Range: YC0681--YC0768 Superseded by part number: 2444Z2448F3 |
| 92. | 2432Z290D6 | [5] | CLIP | KOBWire Ties -- 292mm Long Superseded by part number: PY01P01043D5 |
| 93. | 2414Z199D025 | [5] | PROTECTIVE SLEEVE | KOBHose -- 250mm Long (9-27/32 in) |
| 95. | ZA23F10004 | [2] | HYD CONNECTOR | KOB1/4" PF x M16x1.50 x 33mm Long |
| 96. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 100. | 2418T19232 | [1] | PLATE | KOB |
| 101. | ZS13C10025 | [2] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 102. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 103. | 2444Z2337 | [9] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 104. | 2420R537D054 | [1] | FLEXIBLE HOSE,9.60mm ID x 540mm L | KOB Superseded by part number: 2420R537D055 |
| 105. | ZH32X06000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 106. | 2410T323 | [1] | BLOCK | KOB |
| 107. | ZS13C08040 | [2] | SCREW | KOBM08x1.25x40mm Superseded by part number: ZS18C08040 |
| 109. | 2420R349D085 | [2] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 110. | ZX15K08090 | [2] | FLEXIBLE HOSE | KOB |
| 112. | ZS23C06030 | [8] | SCREW,Hex Socket Head, M6 x 30mm | KOBM06x1.0x30mm |
| 113. | ZW22K06000 | [8] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 114. | ZW11K06000 | [8] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 115. | ZN18C14011 | [2] | NUT | KOBM14x2.0mm |
| 120. | 2414U167 | [2] | BOOT | KOB |
| 126. | 2444Z3281 | [1] | ELBOW | KOB |
| 127. | 2444Z2338 | [3] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| 128. | ZH52X06000 | [1] | TEE,30 Degree Fl, Male, PF 3/8" x 3/8" x 3/8", O-Ring | KOB3/8"PFx54mm Long (Incls. O-Ring ZD12P01400) |
| 129. | 2444R941D9 | [1] | FLEXIBLE HOSE | KOB800mm Long (31-1/2 in) |
| 130. | 2444Z2477F1 | [2] | HYD CONNECTOR | KOB |
| 132. | 2444T2592 | [1] | TEE | KOB3/8" PF - 1/4" PF (No O-Ring supplied) |
| 134. | 2444Z3280 | [1] | HYD CONNECTOR | KOB |
| 135. | 2418P20737 | [1] | RIGID TUBE | KOB |
| 136. | ZX15K08250 | [1] | FLEXIBLE HOSE | KOB |
| 137. | ZH51M08006 | [2] | TEE | KOBTEE |
| 138. | 2418T16720 | [1] | RIGID TUBE | KOB |
| 140. | 2432Z290 | [20] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 141. | 2420Z1188 | [3] | GROMMET | KOB |
| 142. | 2420R564 | [1] | GROMMET | KOB |
| 146. | 2420R537D200 | [1] | HOSE,9.60mm ID x 2000mm L | KOB |
| 161. | ZX15K08025 | [1] | KIT | KOB |
| 162. | 2420R349D260 | [1] | HOSE | KOB2600mm Long (102-23/64 in) Superseded by part number: HX21E04260DX |
| 163. | 2420R537D320 | [1] | HOSE ASSY.,9.60mm ID x 3200mm L | KOB3200mm Long (126 in) |
| 164. | 2420R537D275 | [1] | HOSE,9.60mm ID x 2750mm L | KOB Superseded by part number: HX21E06275DX |
| 165. | 2420R537D280 | [1] | HOSE,9.60mm ID x 2800mm L | KOB |
| 166. | 2420R537D260 | [2] | HOSE,9.60mm ID x 2600mm L | KOB |
| 167. | 2420R537D315 | [1] | FLEXIBLE HOSE,9.60mm ID x 3150mm L | KOB Superseded by part number: HX21E06315DX |
| 168. | 2420R537D270 | [1] | FLEXIBLE HOSE,9.60mm ID x 2700mm L | KOB2700mm Long (106-19/64 in) |
| 169. | 2420R537D335 | [1] | FLEXIBLE HOSE,9.60mm ID x 3350mm L | KOB Superseded by part number: HX21E06335DX |
| 170. | 2406R256F1 | [2] | HANDLE | KOB |
| 171. | 2436U1287F1 | [2] | PILOT VALVE | KOB, Serial Range: YC0301-YC0572 Superseded by part number: 2436U1287F3 |
| . . | 2436U1287F3 | [2] | PILOT VALVE | KOB, Start Serial: YC0573 |
| 172. | 2444Z2432 | [1] | TEE | KOB1/4" PF x (2) 3/8" PF x 52mm Long (Incls. O-Ring ZD12P01400) |
| 173. | 2444R963D3 | [1] | HOSE | KOB |
| 176. | 2444Z3761 | [1] | TEE | KOB, Start Serial: YC0573 |
| 177. | 2444Z3783 | [1] | 90 ELBOW | KOB90° -- 1/4" PT (Incls. O-Ring ZD12P01100), Start Serial: YC0573 |
| 178. | 2444Z3766 | [1] | ELBOW | KOB, Start Serial: YC0573 |
| 179. | 2444Z4080 | [2] | HYD CONNECTOR | KOB, Start Serial: YC0769 |
