凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (02-001) - PARTS GROUP, SINGLE BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
416 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
342478A1
|
[4] |
LATCH
|
BN
Swell
|
| 2. |
BN307755
|
[2] |
COVER
|
TYR
Single Bin
|
| 3. |
BN307756
|
[2] |
COVER
|
BN
End, Cover Support
|
| 4. |
BN307757
|
[2] |
COVER
|
BN
Side, Cover Support, RH
|
| 5. |
BN307758
|
[2] |
COVER
|
BN
Side, Cover Support, LH
|
| 6. |
BN307759
|
[4] |
COVER
|
BN
Angle, End, Cover Support
|
| 7. |
BN307760
|
[2] |
COVER
|
BN
Angle, Side, Cover Sprt, RH
|
| 8. |
BN307762
|
[2] |
COVER
|
BN
Angle, Side, Cover Sprt, LH
|
| 9. |
BN309886
|
[2] |
COVER
|
BN
Auxiliary Auger Hole
|
| 10. |
BN309887
|
[1] |
COVER
|
BN
Sensor Hole
|
| 12. |
BN50142
|
[32] |
WASHER,5/16", Stainless Steel
|
BN
|
| 17. |
BN50476
|
[36] |
BOLT,5/16"-18 x 0.75", Stainless
|
BN
|
| 19. |
BN313961
|
[32] |
SCREW,Hex, 1/4" x 3/4", SST
|
BN
1/4" X 3/4", HH, STP, SS Superseded by part number: 87270117
|
| 20. |
BN52033
|
[4] |
BOLT,1/4"-20 X 5/8", Stainless Steel
|
BN
|
| 21. |
BN55359
|
[4] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 22. |
BN55361
|
[40] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 24. |
BN65578
|
[4] |
STRIP
|
BN
Safety-Walk-Flextred, 6 X 26
|
